Thermodynamics

  • Energy is transferred spontaneously from a higher temperature system to a lower temperature system.
  • The first law of thermodynamics is a specific case of the law of conservation of energy involving the internal energy of a system and transfers of energy through work and/or heat and may be represented by P-V diagrams.
  • You can summarize the first law of thermodynamics as: ΔU=Q+W, where Q and W are positive for heat added to the gas or work done on the gas.
  • Work done on a gas can also be found using: W=-PΔV.
  • Four types of P-V processes include:
    • Adiabatic: no heat transfer into or out of system
    • Isobaric: constant pressure
    • Isochoric: constant volume
    • Isothermal: constant temperature
  • You can find the work done on a gas as the area under the P-V curve.
  • Temperature rises as you travel up and to the right on a P-V diagram.
  • Heat energy cannot be completely transformed into mechanical work. Nothing is 100% efficient.
  • All natural systems tend toward a higher level of disorder, or entropy. The only way to decrease the entropy of a system is to do work on it.
  • Heat engines convert heat into mechanical work. A Carnot Engine is a theoretical heat engine that operates at maximum possible efficiency.

Thermodynamics

Lecture Slides are screen-captured images of important points in the lecture. Students can download and print out these lecture slide images to do practice problems as well as take notes while watching the lecture.

  1. Intro
    • Objectives
      • Zeroth Law of Thermodynamics
        • First Law of Thermodynamics
        • Work Done on a Gas
          • Example 1: Adding Heat to a System
            • Example 2: Expanding a Gas
              • P-V Diagrams
              • P-V Diagrams II
              • Example 3: PV Diagram Analysis
                • Types of PV Processes
                • Adiabatic Processes
                • Isobaric Processes
                • Isochoric Processes
                • Isothermal Processes
                • Example 4: Adiabatic Expansion
                  • Example 5: Removing Heat
                    • Example 6: Ranking Processes
                      • Second Law of Thermodynamics
                      • Heat Engines
                      • Power in Heat Engines
                        • Heat Engines and PV Diagrams
                          • Carnot Engine
                          • Example 7: Carnot Engine
                            • Example 8: Maximum Efficiency
                              • Example 9: PV Processes
                                • Intro 0:00
                                • Objectives 0:06
                                • Zeroth Law of Thermodynamics 0:26
                                • First Law of Thermodynamics 1:00
                                  • The Change in the Internal Energy of a Closed System is Equal to the Heat Added to the System Plus the Work Done on the System
                                  • It is a Restatement of the Law of Conservation of Energy
                                  • Sign Conventions Are Important
                                • Work Done on a Gas 1:44
                                • Example 1: Adding Heat to a System 3:25
                                • Example 2: Expanding a Gas 4:07
                                • P-V Diagrams 5:11
                                  • Pressure-Volume Diagrams are Useful Tools for Visualizing Thermodynamic Processes of Gases
                                  • Use Ideal Gas Law to Determine Temperature of Gas
                                • P-V Diagrams II 5:55
                                  • Volume Increases, Pressure Decreases
                                  • As Volume Expands, Gas Does Work
                                  • Temperature Rises as You Travel Up and Right on a PV Diagram
                                • Example 3: PV Diagram Analysis 6:40
                                • Types of PV Processes 7:52
                                  • Adiabatic
                                  • Isobaric
                                  • Isochoric
                                  • Isothermal
                                • Adiabatic Processes 8:47
                                  • Heat Is not Transferred Into or Out of The System
                                  • Heat = 0
                                • Isobaric Processes 9:19
                                  • Pressure Remains Constant
                                  • PV Diagram Shows a Horizontal Line
                                • Isochoric Processes 9:51
                                  • Volume Remains Constant
                                  • PV Diagram Shows a Vertical Line
                                  • Work Done on the Gas is Zero
                                • Isothermal Processes 10:27
                                  • Temperature Remains Constant
                                  • Lines on a PV Diagram Are Isotherms
                                  • PV Remains Constant
                                  • Internal Energy of Gas Remains Constant
                                • Example 4: Adiabatic Expansion 10:46
                                • Example 5: Removing Heat 11:25
                                • Example 6: Ranking Processes 13:08
                                • Second Law of Thermodynamics 13:59
                                  • Heat Flows Naturally From a Warmer Object to a Colder Object
                                  • Heat Energy Cannot be Completely Transformed Into Mechanical Work
                                  • All Natural Systems Tend Toward a Higher Level of Disorder
                                • Heat Engines 14:52
                                  • Heat Engines Convert Heat Into Mechanical Work
                                  • Efficiency of a Heat Engine is the Ratio of the Engine You Get Out to the Energy You Put In
                                • Power in Heat Engines 16:09
                                • Heat Engines and PV Diagrams 17:38
                                • Carnot Engine 17:54
                                  • It Is a Theoretical Heat Engine That Operates at Maximum Possible Efficiency
                                  • It Uses Only Isothermal and Adiabatic Processes
                                  • Carnot's Theorem
                                • Example 7: Carnot Engine 18:49
                                • Example 8: Maximum Efficiency 21:02
                                • Example 9: PV Processes 21:51

                                Transcription: Thermodynamics

                                Hi everyone and welcome back to Educator.com. 0000

                                Today's lesson is on thermodynamics. 0002

                                Our objectives are going to be to understand that energy is transferred spontaneously from a higher temperature system to a lower temperature system, to explain the first law of thermodynamics in terms of conservation of energy involving the internal energy of a system, and to represent transfers of energy through work and heat by using PV diagrams. 0006

                                Let us begin by talking about the zeroth law of thermodynamics. 0026

                                The zeroth law of thermodynamics, they added after some other laws of thermodynamics because they needed it to help make all of their proofs work out. 0034

                                It saids if Object (A) is in thermal equilibrium with Object (B), and Object (B) is in thermal equilibrium with Object (C), then Object (A) must be in thermal equilibrium with Object (C). 0041

                                Sounds kind of obvious, but just so we have everything in there, that is the zeroth law of thermodynamics. 0052

                                The first law of thermodynamics is a little bit more practical for our purposes. 0059

                                It says that the change in the internal energy of a closed system is equal to the heat added to the system plus the work done on the system. 0063

                                ΔU, change in internal energy is heat added to plus work done on, and those are for the positive values. 0072

                                This is really just a restatement of the law of conservation of energy applied in the thermal sense. 0079

                                The sign conventions are extremely important. 0085

                                Positive heat is heat added to the system; positive work is work done on the system. 0088

                                If heat is taken from the system, it is negative and if work is done by the system, the work is negative. 0096

                                All right. Let us talk about work done on a gas. 0104

                                Typically we will use the first law of thermodynamics to analyze the behavior of ideal gases.0106

                                It may be useful to explore our understandings of the work done on a gas a little bit though. 0111

                                If you recall, work is force times the displacement -- and we are going to assume that we have it in the same direction so that we do not have to worry about sines/cosines. 0117

                                That is a reasonable assumption as we are talking about thermodynamics, which implies then -- well if we know pressure is force over area, then force must be pressure times area. 0125

                                I could rewrite this as work is equal to pressure times area times δr, but we are going to take another step here. 0137

                                Change in volume is equal to A(δr) and because we have the convention, that work done on the gas is positive, corresponding to a decrease in volume, we will put a negative sign there, so our sign conventions work out. 0149

                                Then we could say that work is equal to -P × δv. 0165

                                All right if work is force multiplied by displacement, then work is pressure times area times displacement and negative -- just there for the sign convention -- replace A × δr with δv and we get that work is minus P(δv). 0183

                                That is going to be extremely helpful as we start analyzing these gas systems. 0198

                                Let us take an example. 0205

                                Five thousands joules of heat are added to a closed system which then does 3,000 J of work. 0207

                                What is the net change in the internal energy of the system? 0212

                                Well, δu is (Q) + (W) -- 5,000 J of heat are added to, added to, so that must be positive, so 5,000 J is positive, which then does 3,000 J of work. 0216

                                If the system is doing the work, that is negative, so -3,000 -- our total change in net internal energy, must be 2,000 J. 0232

                                Or a second example -- a gas is expanded at atmospheric pressure, 101,325 Pa. 0248

                                The volume of the gas was 5 × 106m3. 0254

                                The volume of the gas is now 5 × 10-3m3. 0259

                                How much work was done in the process? 0263

                                Well, work equals -P(δv), so that's (-P) and δ anything is always the final value minus the initial. 0266

                                So that is V-final - V-initial; P is 101,325 Pa; V-final is 5 × 10-3m3... 0291 ...V-initial is 5 × 10-6m3, which implies then that the work is -506 J. 0276

                                All right. Let us talk about another useful tool for analyzing gas systems. 0308

                                It is called the pressure volume diagram or PV diagram.0313

                                We put pressure on the y-axis, volume on the x-axis and we are going to keep the amount of gas constant, so when we talk about PV = NRT, our ideal gas law, pressures on the graph, volumes on the graph, the amount of gas is constant, so that stays constant, (R) is already a gas constant...0317

                                ...we can solve for (T) using the ideal gas law, so a PV diagram shows us pressure, volume, and indirectly temperature, so we can find (T) once we know these other quantities. 0339

                                If we transition from state (A) to state (B) on a PV diagram, the volume is increasing, so our pressure is decreasing. 0355

                                The work done then is going to be the area under the curve from (A) to (B). 0364

                                That area here is going to be our work. 0371

                                As the volume expands, the gas is doing work, so (W) would be negative and as the volume compresses, the work is being done on the gas, (W) is positive. 0379

                                Also important to note here is that as you move up into the right on the graph, you move to higher temperatures. 0389

                                Let us take a look at some analysis using a PV diagram. 0400

                                Using the PV diagram below, find the amount of work required to transition from state (A) to state (B) and then the amount of work required to go from state (B) to state (C). 0403

                                Well let us start out with the work going from (A) to (B). 0415

                                The work in going from state (A) to state (B) is the area under the graph and as we go from (A) to (B), that is just a straight line, there is no area -- no work done. 0418

                                How about the work done as we go from (B) to (C)? 0428

                                Well that is -P × δV or minus 50,000 Pa -- V, is δV is final minus initial, so that is going to be 4 m3- 2 m3 or -100,000 J. 0433

                                Notice that the gas was expanding, the gas was doing work. 0458

                                Work is positive if the work is done on the gas since the gas is doing work it makes sense that we get a negative value for the work done in going from (B) to (C).0461

                                There are several different types of PV processes that we ought to point out, special PV processes. 0472

                                They have some goofy names and they are kind of vocabulary words, so you really just have to memorize these. 0478

                                Adiabatic -- This is when heat (Q) is not transferred into or out of the system; the heat remains constant. 0483

                                That is adiabatic and a PV graph for an adiabatic process looks like this here in the light blue -- adiabatic. 0491

                                Isobaric -- pressure (P) remains constant and in an isobaric process, since (P) remains constant, you have a horizontal line. 0498

                                Isochoric means volume remains constant so that means you have a vertical line and you stay at the same (V). 0508

                                An isothermal means temperature (T) remains constant and you get an isotherm that looks like this -- isothermal lines on a PV diagram, we call isotherms. 0514

                                And we will dive into these in a little bit more detail right away. 0524

                                Adiabatic process -- heat is not transferred into or out of the system -- Q = 0 -- therefore by the first law of thermodynamics, if δU is equal to Q + W, and we know that Q = 0 in an adiabatic process, then the change in internal energy of the gas is the work done on the gas, δU = W. 0529

                                Pretty straightforward and the processes have that sort of shape. 0553

                                An isobaric process -- pressure remains constant. 0560

                                Isobaric -- constant pressure -- the PV diagram shows a horizontal line and if PV = NRT, (P) is constant and then (R) are constant, we can rearrange this to say that V/T = NR/P. 0564

                                If all of that is constant, that means that V/T, that ratio remains constant for any gas processes. 0580

                                That happens in an isobaric or constant pressure process. 0586

                                In an isochoric process, the volume remains constant. 0591

                                In an isochoric, we have constant volume or a vertical line and the work done on the gas is 0, because remember work done on a gas is the area under the graph and in a vertical line, you do not have any area under it and if PV = NRT and volume remains constant, well constant P/T = NR/V. 0595

                                All of those are constant, so the ratio of P/T remains constant for all of your processes. 0620

                                In an isothermal processes where the temperature remains constant, the lines on the PV diagram for these are called isotherms; there is an isothermal process. 0627

                                If PV remains constant, the internal energy of the gas must remain constant. 0638

                                Let us look at an example for an adiabatic expansion. 0647

                                An ideal gas undergoes an adiabatic expansion -- adiabatic -- Q = 0 -- no transfer -- doing 2,000 J of work. 0650

                                How much does the gases internal energy change? 0660

                                Well, δu = Q + W, but since it is adiabatic, we know that Q = 0, so δu = W, which must be - 2,000 J. 0663

                                The biggest trick here is remembering the definitions of these terms. 0681

                                Example 5: Removing some heat -- Heat is removed from an ideal gas as its pressure drops from 2,000 Pa to 100,000 Pa. 0686

                                The gas then expands from a volume of 0.05 m3 to 0.1 m3 as shown in the PV diagram below. 0695

                                If curve (AC) represents an isotherm, find the work done by the gas and the heat added to the gas. 0703

                                Well, right away the work in going from (A) to (B) is 0, because there is no area under that graph and the work going from (B) to (C) is just -P(δv)... 0709

                                ... or -100,000 Pa × V-final - V-initial or 0.1 - 0.05, which is -5,000 J. 0721

                                That is the work done by the gas, that is why it is negative. 0735

                                Now we are on an isotherm going from (A) to (C), so (U) must be constant; our internal energy has to stay the same. 0739

                                Δu = 0, which equals Q + W, therefore, Q = -W = 5,000 J.0746

                                You must have added 5,000 J to the gas. 0758

                                Our key answers -- find the work done by the gas -- the work done by the gas was 5,000 J and the heat added to the gas -- we added 5,000 J. 0768

                                The gas did 5,000 J of work and we added 5,000 J to it. 0782

                                Let us take a look at the PV diagram below and answer these questions. 0790

                                During which process is the most work done by the gas? 0793

                                Well, work done by the gas, that is a negative work or an expanding gas. 0798

                                We see that -- that is the area under the graph going to the right here from (A) to (B), so that must be (A) to (B) here. 0803

                                Going from (B) to (C) is no work or no area and from (C) to (A), we are compressing the gas, so work is being done on it. 0811

                                Again, during which process is the most work done on the gas? 0817

                                That must be going from (C) to (A). 0820

                                We have the most area going from (C) to (A) and we are compressing the gas, so work is being done to the gas. 0823

                                In which state is it the highest temperature? 0829

                                Remember temperature gets bigger as you go up into the right, so that must be state (C). 0831

                                On to the second law of thermodynamics. 0840

                                Heat flows naturally from a warmer object to a colder object and cannot flow from a colder object to a warmer object without doing work on the system. 0842

                                Heat energy also cannot be completely transformed into mechanical work or another way to say that is nothing is 100% efficient. 0851

                                Now all natural systems tend toward a higher level of disorder or entropy. 0859

                                The only way to decrease the entropy of a system is to do work on it. 0864

                                An entropy is kind of a state of disorder. 0868

                                For example, if I had a really cool Lego castle here right now and I dropped it, it is going to become more messy. 0870

                                In the natural state of the world, I am never going to have a bunch of Lego's in all different pieces dropping and then when I look down and go to pick it up, the castle is already built. 0878

                                Things do not get more ordered unless you do work on it. 0886

                                That is the second law of thermodynamics. 0889

                                Now, another way to look at this is in terms of heat engines. 0893

                                Heat engines convert heat into mechanical work. 0896

                                And the efficiency of a heat engine is the ratio of the energy you get out in the form of work to the energy you put in, so typically how these work... you have a high temp reservoir, a place where you create a lot of heat. 0899

                                You use that to do some sort of work. 0913

                                If you have heat energy at the high temp reservoir, some of it becomes productive output and some of it goes into the low temp reservoir, where it is not very useful. 0915

                                The work that you get out is equal to what you put in minus what is left over -- what goes to that low temp reservoir, and the efficiency of your system is going to be what you wanted to work out divided by what you put in. 0926

                                And we will put the absolute value signs around that, just so you do not have to deal with negatives. 0945

                                But W = Qh - Qc/Qh, so you could rewrite that if you wanted as 1 - Qc/Qh. 0950

                                A couple of key things, but the efficiency is one of the key formulas from this slide. 0962

                                Power in heat engines -- Power is the rate at which work is done, work over time. 0969

                                We talked about that back in mechanics. 0974

                                From a heat engine perspective, though, we can take this a little bit further. 0977

                                If efficiency is work over the high temp heat, then we could rewrite that as work is equal to the efficiency times (Qh) or dividing both sides by time -- W/t is efficiency × Qh/t. 0982

                                Work over time is power, so since P = W/t, then power on the left hand side becomes efficiency × Qh/t, but let us go another step. 1002

                                We just found that efficiency could also be written as 1 - Qc/Qh, therefore, P = 1 - Qc/Qh × Qh/t. 1015

                                Well with a little bit more rearrangement and a little more Algebra, P = Qh/t - -- well the Qh's will cancel -- Qc/t. 1037

                                A couple of other ways to help you calculate the power from heat engines. 1051

                                All right. Heat engines and PV diagrams -- On a PV diagram, a heat engine is a closed cycle. 1058

                                For clockwise processes, these are heat engines. 1065

                                If you go in the other direction, counter-clockwise processes -- those are refrigerators. 1068

                                Now let us talk a little bit about the Carnot engine. 1075

                                The Carnot engine is not something that you just go out and buy. 1077

                                It is a theoretical model, a theoretical idea of an engine that has the maximum possible efficiency. 1081

                                It uses only isothermal and adiabatic processes and Carnot's theorem states that no engine operating between two heat reservoirs can be more efficient than the Carnot engine operating between those same two reservoirs. 1087

                                So the Carnot engine is kind of the theoretical model of the maximum efficiency you could get from an engine and the efficiency of the Carnot engine is equal to the temperature of the hot reservoir minus the temperature of the cold reservoir, divided by the temperature of the hot reservoir. 1099

                                When you actually utilize this to do calculations, keep a note that the temperature must be in standard SI units or Kelvins. 1115

                                Let us take another look at a Carnot engine problem. 1129

                                A 35% efficient Carnot engine absorbs 1,000 J of heat per cycle from a high temp reservoir held at 600 K. 1131

                                Find the heat expelled per cycle as well as the temperature of the cold reservoir. 1138

                                Well, if our efficiency is 35% or 0.35, we also know that our Qh is 1,000 J per cycle and that the temperature of our high temp reservoir is 600 K. 1143

                                We could start with efficiency as our high temperature when its our cold temperature divided by our hot temperature for the engine, therefore, efficiency equals 1 - cold temperature/hot temperature or cold temperature/hot temperature is 1 - efficiency. 1163

                                Therefore, to find the cold temperature, (TC) is going to be equal to the hot temperature times 1 - the efficiency or 600 K × 1 - 0.35 = 0.65 × 600 or 390 K. 1184

                                Now we have the heat expelled per cycle as well as the temperature of the cold reservoir, so if we want E = W/Qh and we want to find what that W is, that is going to be E × Qh or our efficiency 0.35 × the heat on the hot side (1,000 J) or 350 J. 1207

                                So then W = Qh - Qc. 1235

                                Therefore, Qc = Qh - W or 1,000 - 350 = 650 J. 1242

                                Let us look at a maximum efficiency problem. 1262

                                Determine the maximum efficiency of a heat engine with a high temperature reservoir of 1200 K and a low temperature reservoir of 400 K. 1265

                                Now, this is not really asking for a Carnot efficiency because the most efficiency you can have is the Carnot engine. 1274

                                The Carnot efficiency is Th - Tc/Th or 1200 K - 400 K/1200 K = 0.667 or about 66.7%. 1283

                                One last problem here -- Which of the following terms best describes a PV process in which the volume of the gas remains constant? 1308

                                Constant volume -- So I check on vocabulary words from those PV processes -- Adiabatic, no that is constant (Q); isobaric -- that is constant pressure; isochoric -- that is constant volume, and isothermal of course is constant temperature. 1320

                                Our correct answer there must be C. 1337

                                Hopefully that will give you a good start in thermodynamics. 1340

                                I appreciate your time and thanks for coming to visit us at Educator.com. 1343

                                Make it a great day everyone!1347
