Temperature, Heat, & Thermal Expansion

  • The internal energy of an object, known as its thermal energy, is related to the kinetic energy of all the particles comprising the object. Because there is a range of particle kinetic energies, the system is modeled as a distribution of kinetic energies and analyzed using Maxwell-Boltzmann statistics.
  • The total thermal energy is the sum total of the kinetic energies of the constituent particles.
  • The average kinetic energy of the particles is directly related to the temperature of the object.
  • Even though two objects can have the same temperature (and therefore kinetic energy), they may have different internal energies.
  • Heat is the transfer of thermal energy from one object to another object due to a difference in temperature.
  • Conduction is a thermal energy transfer process in which particle collisions transfer momentum from on object to another. After many collisions, both systems of particles have the same temperature. On the microscopic scale, this is a probabilistic process.
  • Heat transfers by conduction, convection, and radiation.
  • When objects are heated, they tend to expand. When they are cooled, they tend to contract.

Temperature, Heat, & Thermal Expansion

Lecture Slides are screen-captured images of important points in the lecture. Students can download and print out these lecture slide images to do practice problems as well as take notes while watching the lecture.

  1. Intro
    • Objectives
      • Thermal Physics
      • Temperature
      • Temperature and Phases of Matter
      • Average Kinetic Energy and Temperature
      • Temperature Scales
        • Converting Temperatures
          • Heat
          • Methods of Heat Transfer
          • Quantifying Heat Transfer in Conduction
          • Thermal Conductivity
            • Example 1: Average Kinetic Energy
              • Example 2: Body Temperature
                • Example 3: Temperature of Space
                  • Example 4: Temperature of the Sun
                    • Example 5: Heat Transfer Through Window
                      • Example 6: Heat Transfer Across a Rod
                        • Thermal Expansion
                        • Linear Expansion
                        • Volumetric Expansion
                        • Coefficients of Thermal Expansion
                          • Example 7: Contracting Railroad Tie
                            • Example 8: Expansion of an Aluminum Rod
                              • Example 9: Water Spilling Out of a Glass
                                • Example 10: Average Kinetic Energy vs. Temperature
                                  • Example 11: Expansion of a Ring
                                    • Intro 0:00
                                    • Objectives 0:12
                                    • Thermal Physics 0:42
                                      • Explores the Internal Energy of Objects Due to the Motion of the Atoms and Molecules Comprising the Objects
                                      • Explores the Transfer of This Energy From Object to Object
                                    • Temperature 1:00
                                      • Thermal Energy Is Related to the Kinetic Energy of All the Particles Comprising the Object
                                      • The More Kinetic Energy of the Constituent Particles Have, The Greater the Object's Thermal Energy
                                    • Temperature and Phases of Matter 1:44
                                      • Solids
                                      • Liquids
                                      • Gases
                                    • Average Kinetic Energy and Temperature 2:16
                                      • Average Kinetic Energy
                                      • Boltzmann's Constant
                                    • Temperature Scales 3:06
                                    • Converting Temperatures 4:37
                                    • Heat 5:03
                                      • Transfer of Thermal Energy
                                      • Accomplished Through Collisions Which is Conduction
                                    • Methods of Heat Transfer 5:52
                                      • Conduction
                                      • Convection
                                      • Radiation
                                    • Quantifying Heat Transfer in Conduction 6:37
                                      • Rate of Heat Transfer is Measured in Watts
                                    • Thermal Conductivity 7:12
                                    • Example 1: Average Kinetic Energy 7:35
                                    • Example 2: Body Temperature 8:22
                                    • Example 3: Temperature of Space 9:30
                                    • Example 4: Temperature of the Sun 10:44
                                    • Example 5: Heat Transfer Through Window 11:38
                                    • Example 6: Heat Transfer Across a Rod 12:40
                                    • Thermal Expansion 14:18
                                      • When Objects Are Heated, They Tend to Expand
                                      • At Higher Temperatures, Objects Have Higher Average Kinetic Energies
                                      • At Higher Levels of Vibration, The Particles Are Not Bound As Tightly to Each Other
                                    • Linear Expansion 15:11
                                      • Amount a Material Expands is Characterized by the Material's Coefficient of Expansion
                                      • One-Dimensional Expansion -> Linear Coefficient of Expansion
                                    • Volumetric Expansion 15:38
                                      • Three-Dimensional Expansion -> Volumetric Coefficient of Expansion
                                      • Volumetric Coefficient of Expansion is Roughly Three Times the Linear Coefficient of Expansion
                                    • Coefficients of Thermal Expansion 16:24
                                    • Example 7: Contracting Railroad Tie 16:59
                                    • Example 8: Expansion of an Aluminum Rod 18:37
                                    • Example 9: Water Spilling Out of a Glass 20:18
                                    • Example 10: Average Kinetic Energy vs. Temperature 22:18
                                    • Example 11: Expansion of a Ring 23:07

                                    Transcription: Temperature, Heat, & Thermal Expansion

                                    Hi everyone and welcome back to Educator.com. 0000

                                    I am Dan Fullerton and I am thrilled to be opening up our unit today on thermophysics. 0003

                                    We are going to start with heat temperature and thermal expansion. 0008

                                    Our objectives are going to be to calculate the temperature of an object given its average kinetic energy, to describe the temperature of a system in terms of a distribution of molecular speeds, and describe thermal equilibrium as a probability process where energy is typically transferred from high to low energy particles. 0011

                                    We will also explain heat as the process of transferring energy between systems at different temperatures, and finally calculating the linear and volume metric expansion of a solid as a function of its temperature.0027

                                    Let us talk about thermophysics. 0042

                                    Thermophysics explores the internal energy of objects due to the motion of the atoms and molecules comprising the objects. 0045

                                    It explores the transfer of this energy from object to object, known as heat, a transfer mechanism for energy. 0052

                                    Let us start with temperature. 0061

                                    The internal energy of an object, known as its thermal energy is related to the kinetic energy of all the particles comprising the object. 0063

                                    The more kinetic energy the constituent particles have as they move in their vibrations as part of that object, the greater the objects thermal energy. 0071

                                    For most systems, the kinetic energy of the constituent particles is not the same, it is a distribution, therefore the system is modeled as a distribution of kinetic energies, typically using Maxwell Boltzmann's statistics. 0080

                                    As we talk about temperature and phases of matter, in solids the particles comprising the solids are held together very tightly, therefore their motion is limited to just vibrating back and forth in their given positions. 0103

                                    In liquids, the particles can move back and forth across each other, but the object itself does not have a defined shape. 0116

                                    In gases, the particles move throughout the entire volume available, but in all cases the total thermal energy is the sum of the kinetic energies of the constituent particles. 0122

                                    Average kinetic energy and temperature -- actual kinetic energies of individual particles may vary significantly and the average kinetic energy we can find by taking 3/2 times this constant Kb, known as Boltzmann's constant times the temperature and that temperature should be in Kelvins (K), our si unit of temperature. 0136

                                    If Kb is Boltzmann's constant, that is 1.38 × 10-23 J/K -- the temperature is in Kelvins, the si unit of temperature again, not Celsius, not Fahrenheit, but Kelvins. 0157

                                    Now it is important to note that even though two objects can have the same temperature and therefore the same average kinetic energy, they may have different internal energies, depending on what those particles that are moving are. 0172

                                    Let us take a look at some temperature scales. 0186

                                    We have Fahrenheit (F) on the left, Celsius (C) in the center, and Kelvins (K) on the right. 0189

                                    Now they all work in the same basic way, but they have different values at different key temperature readings. 0194

                                    The Fahrenheit scale has water freezing at 32 ° F and water boiling at 212 ° F and if you extrapolate that back, you get to what is known as absolute 0 at about -459.7 ° F, where absolute 0 is a theoretical minimum temperature. 0199

                                    It is the point on a volume vs. temperature graph on a gas where the extended curve would hypothetically reach 0 volume. 0220

                                    It is not specifically the absolute lack of motion of particles, it is a theoretical minimum, but for our purposes, really cold and you do not get any colder than that. 0230

                                    For Celsius, water boils at 100 ° C, freezes at 0 ° C, and absolute 0 would be -273.15 ° C. 0240

                                    Now Kelvins, the scale we are going to use here in physics -- and Kelvins has the same size of its main unit, a Kelvin -- 100 ° between water freezing and boiling, but the only difference is we are going to start 0 at absolute 0. 0250

                                    That means that water freezes at 273.15 K and it boils at 373.15 K. 0268

                                    Converting between temperature scales is fairly straight forward. 0277

                                    If you know Celsius, to get Kelvins, you add 273.15. 0280

                                    If you know Celsius and you want Fahrenheit, multiply the Celsius temperature by 9/5 and add 32. 0286

                                    If you know Fahrenheit and you want Celsius, take the Fahrenheit temperature, subtract 32 and multiply by 5/9. 0293

                                    Now let us talk about heat as the transfer of thermal energy from one object to another object due to their difference in temperature. 0304

                                    That is typically accomplished through some sort of particle interactions or collisions in which momentum is transferred from one object to another. 0313

                                    That is conduction. 0319

                                    Now energy is typically transferred from higher energy to lower energy particles and after many collisions, both systems of particles likely have the same average temperature. 0322

                                    That does not mean that every collision works this way, but on the average it goes in that general direction. 0330

                                    Because the particles comprising objects have a distribution of particles, velocities, and energies, on the microscopic scale, this transfer of energy is a probabilistic process. 0335

                                    So as you look at it more and more closely, you have to get more and more into statistics of distribution. 0345

                                    So methods of heat transfer -- We can transfer heat from one object to another by three different methods. 0353

                                    Conduction is the transfer of energy along an object to the particles comprising the object colliding. 0359

                                    Think of sticking an iron rod in the fire. 0364

                                    Okay, the fiery end is going to get hot real quick, but if you hold that long enough, the other end that started off cool is going to get pretty hot. 0368

                                    That is by the transfer of the energy from particle to particle to particle in that object. 0374

                                    Convection is the transfer of energy as a result of energy or heated particles moving from one place to another, like the convection ovens -- heated air molecules move from one place to another. 0379

                                    And radiation is the transfer of energy through electromagnetic waves. 0389

                                    Now as we try and quantify heat transfer in conduction, we can get a look at the rate of heat transfer, (H) in J/s or also watts (W). 0397

                                    Heat is K × A × δt/L, where δt is your temperature gradient, the difference in temperature; (A) is the cross-sectional area, (L) is the length of your object, and (K) is a thermal conductivity depending on the material, typically something you would look up, a material property. 0407

                                    Now, I have put in here a table of some thermal conductivities of selected materials and on the left we have materials such as aluminum, concrete, copper, glass, stainless steel, and water and on the right they are thermal conductivities in J/(s-m-K). 0432

                                    For example, copper has a much higher thermal conductivity than something like water. 0447

                                    Let us see how we can put this into practice. 0455

                                    What is the average kinetic energy of the molecules in a steak at a temperature of 345 K?0458

                                    Well the average kinetic energy is given by 3/2 times Boltzmann's constant times the temperature. 0464

                                    So that will be 3/2 × 1.38 × 10-23 (Boltzmann's constant) and a temperature of 345 K is going to give us an average kinetic energy of about 7.14 × 10-21 J. 0474

                                    Let us take a look at another example this time dealing with body temperature. 0498

                                    Normal canine body temperature is 101.5 F. What is normal canine body temperature in degrees C and K?0504

                                    Well let us convert temperature in degrees C -- is 5/9 times the temperature in degrees F minus 32. 0513

                                    So that will be 5/9 × 101.5 - 32 = 38.6 ° C. 0523

                                    Now let us convert that to K. 0539

                                    Temperature in K is the temperature in degrees C plus 273.15, so that will be 38.6 + 273.15 = 311.75 K. 0543

                                    Let us look at the temperature of space. 0570

                                    The average temperature of space is estimated as roughly -270 ° C, that is cold. 0574

                                    What is the average kinetic energy of the particles in space? 0579

                                    Well, first thing we are going to do is convert to K, so the temperature in K is the temperature in degrees C plus 273.15, so that will be -270 + 273.15 = 3.15 K. 0583

                                    Average kinetic energy then, is going to be 3/2 times Boltzmann's constant times our temperature, or 3/2 × 1.38 × 10-23 × 3.15 K (temperature) or 6.5 × 10-23 J. 0608

                                    All right, let us look at the temperature of the sun. 0644

                                    Given the average kinetic energy of the particles comprising our sun is 1.2 × 1019 J. 0648

                                    Find the temperature of the sun in K. 0654

                                    Well, if average kinetic energy is 3/2 Kbt, then that means the temperature must be 2 times the average kinetic energy divided by 3 times that Boltzmann's constant, Kb. 0658

                                    Or 2 × 1.2 × 1019 J/3 × 1.38 (Boltzmann's constant) × 10-23, or 5800 K. 0675

                                    Let us take a look at a heat transfer problem. 0698

                                    Let us find a rate of heat transfer through a 5 mm thick glass window with a cross-sectional area of 0.4 m2 if the inside temperature is 300 K and the outside temperature is 250 K. 0701

                                    Well the rate of heat transfer (h) is Kaδt/L, where if we look up (K) for glass, we can find that the thermal conductivity of glass is about 0.9. 0713

                                    So that is going to be 0.9 times the cross-sectional area (0.4) times δt, the change in temperature, is 50 K (temperature gradient) divided by our length (5 mm or 0. 0.005 m). 0729

                                    So our heat transfer rate is going to be about 36 J/s or 3600 W. 0748

                                    Let us look at heat transfer across a rod. 0761

                                    One end of a 1.5 m stainless steel rod is placed in an 850 K fire. 0764

                                    The cross-sectional area of the rod is 1 cm and the cool end of the rod is at 300 K. 0770

                                    Calculate the rate of heat transfer through the rod. 0776

                                    Well, first let us figure out that cross-sectional area. 0779

                                    Area is πr2, so that is going to be π times our radius (1 cm), so that is 0.1 m2 or 3.14 × 10-4m2. 0782

                                    Now we are also going to need the thermal conductivity of steel and there are different conductivities depending on the types of steel, but let us just assume an average thermal conductivity of steel, rough estimate of about 16.5. 0801

                                    Our rate of heat transfer (h) is Kaδt/L, where (K) for steel is 16.5. 0818

                                    Our cross-sectional area, we just determined was 3.14 × 10-4m2 and our temperature gradient from 850 K to 300 K is 550 K...0828

                                    ...divided by the length of our rod 1.5 m or 1.9 J/s or 1.9 W. 0842

                                    All right, so you know when objects are heated, they tend to expand and when they are cool, they tend to contract and at higher temperatures, objects have higher average kinetic energies so their particles vibrate more. 0857

                                    At those higher levels of vibrations those particles are not bound as tightly to each other, so the object expands -- exact opposite, as it cools down, they do not vibrate as much and they are bound a little bit more tightly, so they contract. 0870

                                    This is why if you have a stuck jar of pickles or something and you are trying to open it and you cannot quite untwist it, go try and run it under hot water because if you run it under hot water, the lid is going to start expanding. 0885

                                    It is going to expand at a faster rate than the glass, so if you run it under hot water, you give yourself a little bit more room and you loosen it up so hopefully, now you are strong enough to undo the lid. 0898

                                    Linear expansion -- the amount of material expands is characterized by the materials coefficient of expansion. 0912

                                    One-dimensional expansion, we use the linear coefficient of expansion which gets the symbol α.0918

                                    So the change in an object's length due to linear expansion is this -- linear coefficient of expansion times its initial length times its change in temperature (δt). 0925

                                    For volumetric expansions, the amount of material that expands is again characterized by the coefficient of expansion, but if it is three-dimensional expansion, you use the volumetric coefficient of expansion, which gets the symbol β. 0938

                                    The change in volume is that coefficient of expansion, the volumetric coefficient of expansion, β times the initial volume times the change in temperature. 0951

                                    In most cases the volumetric coefficient of expansion is roughly 3 times the linear coefficient of expansion and that change in temperature can be provided in either ° C or K because the sign of the individual units are the same and we are looking at a relative change, not an absolute C or K -- it does not really matter for these problems. 0963

                                    So, some coefficients of thermal expansion again. 0984

                                    We have aluminum, concrete, diamond, glass, stainless steel, and water and we have the linear coefficient of expansion and the volumetric coefficient of expansion. 0987

                                    Now water is a little bit tricky here. 0996

                                    Although I have included it here, it actually expands when it freezes, so calculations near the freezing point of water require a little more detailed analysis than is provided here. 0999

                                    There is a window of a couple of degrees in water, that make it a little bit more complicated, so just keep that in mind, that this is not the full story for water. 1008

                                    Let us take a look at a contracting railroad tie. 1020

                                    A concrete railroad tie has a length of 2.45 m on a hot sunny 35 ° C day. 1023

                                    What is the length of the railroad tie in the winter when the temperature dips to -25 ° C? 1029

                                    Well, if it is a concrete railroad tie, let us find the linear coefficient of expansion for concrete and for concrete, that just so happens to be about 12 × 10-6.1036

                                    So, δL is equal to α L-initial δT. 1050

                                    That is 12 × 10-6 × 2.45 m (initial length) × -60 (temperature change) or a total of -0.0018 m. 1059

                                    So what is the new length of the railroad tie? 1078

                                    Well, δL is equal to (L) - L-initial -- δ anything is the final value minus the initial.1080

                                    Therefore the final value is going to be δL + L-initial...1087

                                    ...which will be -0.0018 m + 2.45 m, so its new length will be about 2.448 m. 1095

                                    All right, pretty straightforward. 1115

                                    Let us take a look at the expansion of an aluminum rod. 1117

                                    An aluminum rod has a length of exactly 1 m when it is at 300 K. 1121

                                    How much longer is it when placed in a 400 ° c oven? 1125

                                    Well, a couple of things I am going to need to know here. 1130

                                    First I am going to need to convert this temperature to K, because I start at K and then I am crossing over to C, that is kind of tough to tell the temperature difference between the two. 1133

                                    First, let us convert that -- our temperature in K is our temperature in ° C + 273.15, so that is going to be 400 ° C +273.15 or 673.15 K. 1143

                                    For dealing with the expansion of aluminum, I am also going to have to know that α, the linear coefficient of expansion for aluminum is about 23 × 10-6, so now I can find that shift in length. 1164

                                    Δ L is α L-initial δT or 23 × 10-6 × 1 m (initial length) × 673.15 (change in temperature) to 300 K... 1182

                                    ...is going to be about 373.15 or a total change in length of about 0.0086 m. 1200

                                    How about looking at some volumetric expansion. 1218

                                    A glass of water with volume 1 liter is completely filled at 5 ° C. 1221

                                    How much water will spill out of the glass when the temperature is raised to 85 ° C? 1227

                                    Well, we have to realize here that both the glass and the water are going to expand, so let us see how much each expands and find the difference between those two. 1234

                                    If we start with the water, the change in volume is going to be β, the volumetric coefficient of expansion times its initial volume times our difference in temperature and the volumetric coefficient of expansion for water (β) is 207 × 10-6, so that is 207 × 10-6 × 1 L × 80 ° or about 0.0166 L. 1244

                                    The glass is a slightly different story. 1267

                                    Change in volume is (β)(V0δT) again, but the volumetric coefficient of expansion for the glass is 27 × 10-6 × 1 L × 80 ° or about 0.0022 L. 1291

                                    We have considerably more expansion from the water than the glass, so how much is going to spill out? 1312

                                    We are going to take the difference of these two, 0.0166 L - 0.0022 L to find out that we have 0.0144 L spilling out. 1318

                                    All right, let us take a look at an example problem where we are looking at some graphs of average kinetic energy vs. temperature. 1338

                                    Which graph best represents the relationship between the average kinetic energy of the random motion of the molecules of an ideal gas in its absolute temperature. 1344

                                    Well, first of all, let us write down that relation. 1353

                                    The average kinetic energy is 3/2 Boltzmann's constant times (t). 1356

                                    Notice that we have a direct linear relationship between the average kinetic energy and the temperature. 1365

                                    As temperature goes up, average kinetic energy goes up. 1372

                                    There it is -- our direct linear relationship. 1376

                                    Let us take a look at one more. 1382

                                    Jodie cannot remove her wedding ring. 1387

                                    If she runs the entire ring under hot water, what is going to happen to the hole in the middle>? 1389

                                    Will it expand, contract, or stay the same? Well, here is how we are going to treat this. 1394

                                    We are going to find what happens if we treat this as two rings, an outer ring and an inner ring. 1400

                                    Let us treat it as a circle, a bigger circle and a more little circle. 1407

                                    The big circle is going to expand and the inner circle is also going to expand. 1410

                                    Let us expand them both and then we are going to recombine them and when we do that what we are going to find is if the inner one has expanded and the outer one has expanded, of course this is where the finger goes inside that one and that one is expanded as well, therefore, they both expand. 1418

                                    In linear expansion, every linear dimension of an object changes by the same fraction when it is heated or cooled. 1434

                                    That is a good way to get the ring off -- run it under hot water, hopefully it expands -- maybe try a little bit of dish soap or some lubricant there as well. 1441

                                    Hopefully that gets you a good start on temperature, heat, and thermal expansion. 1450

                                    Thank you so much for your time and make it a great day! 1454

                                    We will see you soon.1457
