Area Under A Curve

  • Approximating area under curve using rectangles
    • Setup appropriate intervals and evaluate f(xi)
    • Sum all of f(xi)
  • To avoid confusion, think physical, geometric area, rather than calculus

Area Under A Curve

Find the area under the curve f(x) = x on interval [0,5] using 5 rectangles and the right-endpoint
  • f(1) = 1
  • f(2) = 2
  • f(3) = 3
  • f(4) = 4
  • f(5) = 5
  • Area under the curve is approximately equal to [(5 − 0)/5](1 + 2 + 3 + 4 + 5)
Area is approximately equal to 15
Find the area under the curve f(x) = x on interval [0,5] using 5 rectangles and the left-endpoint
  • f(0) = 0
  • f(1) = 1
  • f(2) = 2
  • f(3) = 3
  • f(4) = 4
  • Area under the curve is approximately equal to [(5 − 0)/5](0 + 1 + 2 + 3 + 4)
Area under the curve is approximately equal to 10
Find the area under the curve f(x) = x2 on interval [−2,2] using 4 rectangles and the right-endpoint
  • f(−1) = 1
  • f(0) = 0
  • f(1) = 1
  • f(2) = 4
  • Area under the curve is approximately equal to [(2 − (−2))/4](1 + 0 + 1 + 4)
Area under the curve is approximately equal to 6
Find the area under the curve f(x) = 3cosx on interval [−[(π)/2],[(π)/2]] using 4 rectangles and the right-endpoint
  • f(−[(π)/4]) = 3 cos−[(π)/4] = [3/(√2)]
  • f(0) = 3 cos0 = 3
  • f([(π)/4]) = 3 cos[(π)/4] = [3/(√2)]
  • f([(π)/2]) = 3 cos[(π)/2] = 0
  • Area under the curve is approximately equal to [([(π)/2] − (−[(π)/2]))/4]([3/(√2)] + 3 + [3/(√2)] + 0)
A ≈ [(π)/4](3 + [6/(√2)])
Find the area under the curve f(x) = x + 3 on interval [0,1] using 4 rectangles and the right-endpoint
  • Find the width of each rectangle
  • [(1 − 0)/4] = .25
  • f(.25) = 3.25
  • f(.5) = 3.5
  • f(.75) = 3.75
  • f(1) = 4
  • Area under the curve is approximately equal to .25(3.25 + 3.5 + 3.75 + 4)
A ≈ 3.625
Find the area under the curve f(x) = x + 3 on interval [0,1] using 10 rectangles and the right-endpoint
  • Find the width of each rectangle
  • [(1 − 0)/10] = .1
  • f(.1) = 3.1
  • f(.2) = 3.2
  • f(.3) = 3.3
  • f(.4) = 3.4
  • f(.5) = 3.5
  • f(.6) = 3.6
  • f(.7) = 3.7
  • f(.8) = 3.8
  • f(.9) = 3.9
  • f(1) = 4
  • Area under the curve is approximately equal to [(1 − 0)/10](3.1 + 3.2 + 3.3 + 3.4 + 3.5 + 3.6 + 3.7 + 3.8 + 3.9 + 4)
A ≈ 3.55
Find the area under the curve f(x) = x2 + 3x + 1 on interval [−1,1] using 2 rectangles and the right-endpoint
  • [(1 − (−1))/2] = 1
  • f(0) = 1
  • f(1) = 1 + 3 + 1 = 5
  • Area under the curve is approximately 1(1 + 5)
A ≈ 6
Find the area under the curve f(x) = sin2x on interval [0, [(π)/2]] using 2 rectangles and the left-endpoint
  • [([(π)/2] − 0)/2] = [(π)/4]
  • f(0) = sin0 = 0
  • f([(π)/4]) = [1/(√2)]
  • Area under the curve is approximately equal to [(π)/4](0 + [1/(√2)])
A ≈ [(π)/(4√2)]
Find the area under the curve f(x) = sinx on interval [−[(π)/2], [(π)/2]] using 4 rectangles and the left-endpoint
  • [([(π)/2] − (−[(π)/2]))/4] = [(π)/4]
  • f(−[(π)/2]) = sin[(−π)/2] = −1
  • f(−[(π)/4]) = sin[(−π)/4] = −[1/(√2)]
  • f(0) = sin0 = 0
  • f([(π)/4]) = sin[(π)/4] = [1/(√2)]
  • Area under the curve is approximately equal to [(π)/4](−1 − [1/(√2)] + 0 + [1/(√2)])
A ≈ −[(π)/4]
Find the area under the curve f(x) = sinx on interval [−[(π)/2], [(π)/2]] using 4 rectangles and the right-endpoint
  • [([(π)/2] − (−[(π)/2]))/4] = [(π)/4]
  • f(−[(π)/4]) = sin[(−π)/4] = −[1/(√2)]
  • f(0) = sin0 = 0
  • f([(π)/4]) = sin[(π)/4] = [1/(√2)]
  • f([(π)/2]) = sin[(π)/2] = 1
  • Area under the curve is approximately equal to [(π)/4](− [1/(√2)] + 0 + [1/(√2)] + 1)
A ≈ [(π)/4]
