Torque on a Current Carrying Loop

If the magnetic field B is parallel to the plane of a loop carrying a current I, the torque exerted by B on the loop is IAB, where A is the area of the loop.
In general, the torque is given by I A x B, where A is a vector whose magnitude is the loop area and which is directed normal to the loop plane.
The magnetic moment of a loop of area A carrying a current I is the product m = IA and is directed normal to the plane of the loop: if the four fingers of the right hand circle around in the direction of the current, then the thumb points in the direction of m.
The torque exerted by a magnetic field B on a magnetic moment m is given by the cross product m x B. The potential energy of a magnetic dipole m in a magnetic field B is the dot product –m.B.

Torque on a Current Carrying Loop

Lecture Slides are screen-captured images of important points in the lecture. Students can download and print out these lecture slide images to do practice problems as well as take notes while watching the lecture.

Intro

B-Field Parallel to Plane of the Loop

B-Field Not Parallel to Plane of the Loop

Magnetic Moment

Example

Example 1: Loop in Magnetic Field

Example 2: Rotating Charge
