### Transcription: Complex Numbers

*Hello, welcome back to www.educator.com and welcome back to Physical Chemistry.*0000

*Today, we are going to take a little bit of a detour from the Quantum mechanics and we are going to talk about complex numbers.*0004

*Let us get started.*0010

*Complex numbers, we represent √-1 with an I, so I² = -1.*0014

*Complex numbers are represented this way.*0026

*We usually use the letter Z for a complex number and it is something like A + B I.*0029

*A is the real part of the complex number Z and B we call the imaginary part of the complex number Z.*0038

*Again, z is the standard variable just like X.*0051

*For real numbers, we use Z for complex numbers.*0055

*Geometrically, the complex numbers are represented in a 2 dimensional plane.*0057

*Geometrically, we represent complex numbers in 2 dimensional plane called the complex plane, with something like this.*0066

*This is the real axis, the real number line that you are used to.*0101

*And here we just call it the imaginary axis.*0104

*Again, this is just a pictorial way of actually representing a complex number.*0107

*If we have some complex number like this, let us say we mark a couple of points here 1,*0111

*this is -1 and on the imaginary axes this becomes +I and this becomes –I.*0117

*If I have some complex number like that, this is going to be the B this part and in this part right here that is going to be the A.*0122

*That is it, nice and simple.*0142

*Let us talk about some operations with complex numbers.*0144

*Our operations, you can add, subtract, multiply, and divide complex numbers the way you do any others.*0147

*Let us talk about addition first.*0155

*I think it is best represented with an example here.*0160

*Addition, if I have 2 + 3 I + 7 – 4 I, what you are going to do is you are going to add*0163

*the real part with the real part and you are going to add the imaginary part with the imaginary part.*0175

*It ends up being 2 + 7 = 9, 3 -4 = -1 I.*0181

*There you go, 9 – I, nice and simple.*0190

*Let us talk about subtraction, it is the same exact thing.*0198

*You are just going to be changing some signs.*0202

*Subtraction, let us do the same thing.*0205

*Let us do 2 + 3 I this time we will subtract 7 -4 I.*0207

*Once again, you are just going to put 2 -7 = -5 and you have 3 I—4 I = +7 I.*0213

*Nothing very strange about it.*0226

*Multiplication is also very straightforward.*0228

*For multiplication you are just going to treat it like you would any other binomial.*0232

*We have 2 + 3 I and we have the 7 -4 I so we are going to do this with this, the inside the outside, that same thing.*0245

*Or if you want this with this, this with this, and this with this.*0256

*How you do it actually does not matter.*0259

*2 × 7 we have 14 and we have to the inside we have + 21 I, we have -8 I, and here we have this is -3 × 4 = 12.*0262

*I × I = I² and I² = -1.*0280

*This becomes 14, 21 I -8 I = 13 I.*0284

*I hope you are checking my arithmetic, I'm notorious for being bad at arithmetic.*0291

*And this becomes + 12, this becomes 26 + 13 I.*0296

*Just multiply it out.*0304

*Before I do division, I want to introduce the notion of complex conjugate.*0308

*If A + B I is a complex number, then its complex conjugate which is denoted as Z*.*0315

*Z* = A – BI.*0340

*Basically, all you are doing is switching the + to A - .*0344

*Geometrically, it look something like this.*0348

*If this is the complex number, its conjugate is just a reflection along the x axis.*0351

*A + B I, A – B I, that is all it is.*0359

*Let us go ahead and do a division here.*0365

*Now, we have 2 + 3 I and we would divide that by the 7 -4 I.*0370

*We are going to multiply the top and bottom by the complex conjugate which is multiplying by 1.*0378

*We are going to end up multiplying the top and bottom.*0385

*7 -4 I the conjugate is 7 + 4 I / 7 + 4 I.*0388

*You have seen all this before but it is always nice to do a little bit of a review*0394

*because complex numbers are going to be very complex numbers and complex functions.*0398

*Very important in Quantum Mechanics.*0401

*We multiply the top we end up with 14, this is going to be + 21 I, this is going to be +8 I, and this is going to be + 12 I² ÷ 7 × 7 = 49.*0406

*This is going to be 4 × 4 this is going to be -16 I² and this is going to equal.*0425

*This is going to equal 14 + 39 I, this is +12 I², I² is -1 so it becomes -12.*0433

*Again, mostly this is just an arithmetic issue.*0450

*Keeping all the positives and negatives in order.*0452

*This is going to be I² is -1 so this is going to be 49 + 16 and we are going to get the 14 -12 =2 + 39 I ÷ 65.*0456

*Given a complex numbers in the form A + Bi this is how you handle the basic operations, very straightforward.*0476

*Let us go back to our geometrical representation.*0486

*Since, we have a geometrical representation in a 2 dimensional plane, this is our origin, this is our complex number.*0490

*We have this and we have this, this distance is A, this distance is B, this is the imaginary axis, this is the real axis.*0500

*Because of a point in the plane, we can also represent complex numbers in the polar form.*0510

*If this is an angle θ and we call this distance R, this R we represent as we call it just the modulus of the complex number.*0517

*Basically, it is just the length of the vector from 0 to the complex number.*0534

*I do not have to refer to it as a vector, it is just the length from the origin to that particular point.*0540

*It is exactly what you think, it is the Pythagorean Theorem.*0548

*It is A² + B² all over the radical.*0550

*R = we represent it that way.*0562

*Again, it is called the modulus of the complex number.*0565

*It is equal to A² + B² under the radical.*0569

*This Z when we squared, it is also equal to Z × Z conjugate.*0577

*Let me go back a little bit.*0592

*I have the Z, the R here that is equal to the A² + B².*0596

*Let us talk about θ, it is just the inverse tan of D/ A.*0600

*If you have R and θ, you can find A and B.*0609

*If you have A and B, you can find R and θ.*0613

*Let us go ahead and there is this relationship here which exists.*0620

*It is equal to Z × Z conjugate.*0628

*Again if you take the Z A + BI multiplied by the conjugate which is A – BI.*0633

*If you do that multiplication you can end up with A² + B²,*0639

*When you get rid of it when you square both sides, you will end up with this relation.*0646

*Reasonably important relation that tends to come up a lot.*0653

*Let us talk about Euler’s formula.*0660

*Euler’s formula says the following, E ⁺I θ = cos θ + I sin θ.*0662

*This is a very important formula.*0681

*Given R and θ, we can express A + BI in the form R × E ⁺I θ.*0684

*Basically, I have this version A + BI or I have this version of the complex number.*0715

*The relationship is as follows so A = R × the cos θ and B = R sin θ.*0720

*You have the relationships now.*0734

*Going one way, if you are given R and θ you can find A, R and θ you can find B.*0736

*You can go from the polar version to the Cartesian version.*0740

*Or if you are given A and B, you can use A and B to find R, and you can use the inverse tan of B and A to find θ.*0742

*You can go both ways.*0752

*This and this, and this and this, allows you to go back and fourth.*0754

*Let us take a look at how this happens.*0762

*A + BI, if A = R cos θ + I × R sin θ which is B.*0765

*I will go ahead and factor out the R.*0781

*I get R × cos θ + I sin θ.*0783

*Cos θ + sin θ = E ⁺I θ.*0794

*I have got R × E ⁺I θ.*0798

*That shows that this and this are equivalent.*0802

*There are different ways of actually writing the complex number.*0808

*Most of the time, this is going to be the most convenient form but occasionally this will be the most convenient form.*0811

*It just depends on what you are doing.*0816

*This is the polar exponential representation of the complex number.*0821

*If Z = RE ⁺Iθ.*0829

*The conjugate equals RE ⁻I θ.*0835

*Remember, positive angle negative angle, we are just reflecting it along the x axis.*0842

*This is very important E ⁺I θ, E ⁻I θ.*0852

*Let us go ahead and do some examples.*0859

*I think that is probably the best thing to do at this point.*0862

*Find the real and imaginary parts of 3 – 2 I².*0866

*Let us just do the math.*0871

*3 -2I² is going to be 3 – 2I.*0873

*We are going to get 3 × 3 = 9, this is going to be – 6I.*0879

*This is going to be -6I, this is going to be +4I².*0889

*We are going to get 9 -12 I – 4, 9 - 4 = 5, 5 -12 I.*0895

*The real part of Z = 5, the imaginary part of Z = -12.*0906

*That is it, very simple.*0918

*Find the real and imaginary parts of E⁻³ + I × π/ 3.*0922

*Let us go ahead and separate this out.*0934

*We have E⁻³ × this is -3 +,*0936

*The exponents are added which means 2 things with the same base are multiplied.*0941

*E⁻³ × E ⁺Iπ/ 3.*0946

*E⁻³ E ⁺I θ =cos θ + I × the sin θ.*0953

*Θ in this case is π/ 3.*0962

*We get E⁻³, the cos π/ 3, π/ 3 is 60°.*0968

*The cos of 60° is going to be ½ + I × 3/ 2 so we get E⁻³/ 2 + I × E⁻³ × 3/ 2.*0975

*Therefore, this is the real part and this is the imaginary part.*1001

*This is the real and this is the imaginary part.*1007

*You are just taking what is given and you are re representing it.*1010

*Express I – rad 3 in the form R E ⁺I θ.*1020

*We know what this is, R = we said it is A² + B² of the radical and we said that θ = the inverse tan of B/ A.*1026

*R = 5² + - rad 3² all over the radical that is going to be equal to 25 + 3 under the radical.*1047

*We have a √28 and θ = the inverse tan of - rad 3/ 5.*1066

*When I do that, I end up with a radium measure of -0.333.*1081

*Z = √28 × e⁰.333 × I.*1093

*There you go, RI of θ.*1103

*This is very straightforward as long as you have the back and forth relationship between the two.*1110

*Express e ⁻π/ 4 + LN 3 in the form A + BI.*1119

*Let us see what we have got.*1127

*I’m going to represent this as E ⁺Iπ/ 4 × E ⁺LN 3 which is equal to E ⁺LN 3 × cos of - I/ 4 + I × sin of -π/ 4.*1132

*Because here θ is -π/ 4.*1161

*This is equal to E × LN 3, cos -A = cos A.*1165

*First quadrant, the cos is positive.*1174

*This stays cos, this becomes the positive cos π/ 4.*1177

*The sin –π/ 4 is –sin π/ 4.*1182

*This turns into –I × sin π/ 4.*1185

*We get E ⁺LN 3, the cos π/ 4 is 1/ rad 2 – 1 × rad 2.*1192

*We know have E ⁺LN 3/ rad 2 – E ⁺LN 3/ rad 2 × I.*1210

*There is your A, there is your B, nice and simple.*1231

*Prove E ⁺Iπ =-1.*1243

*I just thought I would throw this in there.*1246

*It is one of all things that is really cool because you got the most important numbers and mathematics.*1246

*You got 1, you got e, you got I and π.*1252

*There is this really beautiful relationship among them.*1256

*Again, E ⁺Iπ you just represent it in sin cos form.*1258

*E ⁺Iπ= cos π + I × sin π.*1265

*The cos π is -1 and the sin π is 0, so that goes to 0.*1277

*That is it -1 and -1.*1284

*I just want you to see it.*1286

*The Euler’s formula is the cos θ + I sin θ ⁺nth = cos N θ + I × sin N θ.*1296

*Basically, just put the n in here.*1307

*Use this to prove the following trigonometric identity.*1309

*Sin 2 θ=2 sinθ cosθ.*1312

*You remember this trig identity from high school and we are going to prove it using Euler’s formula.*1315

*Let us see what we can do.*1324

*In this particular case, here we are going to let N=2.*1326

*This is going to equal to, we get cos θ + I × sin θ.*1339

*The reason that I pick N = 2 is because we are looking for sin 2 θ.*1349

*Sin 2 θ, I just was this thing here.*1354

*Let me just go ahead and set it equal to 2.*1357

*Cos θ + I sin θ², we need to show that it is actually equals cos 2 θ + I × sin 2 θ.*1360

*Let us go ahead and actually multiply this to prove that this is equal.*1379

*Let us work with this side and multiply it out.*1384

*I get cos² θ + I sin θ cos θ is I sin θ cos θ + 2I sin θ cos θ.*1386

*I’m just multiplying this out and then it is going to be + I² sin² θ.*1400

*This is going to be cos² θ + 2I sin θ cos θ.*1410

*I² is -1 so this is going to be -1 so this is going to be –sin² θ.*1417

*Let me put the real parts together.*1421

*I have cos² θ – sin² θ, that is that one.*1424

*I have +2i × sin θ cos θ.*1430

*I’m going to actually equate the real part of this with the real part of this and the imaginary part of this with the imaginary part of this.*1439

*I end up getting two identities.*1466

*I end up with cos 2 θ = cos² θ – sin² θ.*1469

*I get sin 2 θ= 2 sin θ cos θ.*1479

*Again, what we did was we equated real and imaginary parts on both sides.*1487

*We already know that the Euler’s theorem is roughly using this to prove the identity so there is no question mark as to whether they are equal.*1503

*And that is it, nice and straightforward.*1514

*Consider the following set of functions, the C sub N θ = 1/ 2π × e ⁺I n θ where N can be 0, + or -1, + or -2.*1524

*And θ is in the interval from 0 to 2π inclusive.*1539

*We want to show the following.*1543

*We have 4 things to show.*1545

*We want to show that the integral from 0 to 2π of this function.*1546

*The Z = 0 for all values of N that are not equal to 0.*1552

*The rad with 2π when N does equal 0.*1558

*We want to show that the integral of the Z conjugate × Z.*1564

*The integral of that equals 0, when N and M do not equal each other.*1570

*In other words, like 5 and 3 and.*1575

*The integral from 0 to 2π of that same integrand = 1 when N and M do equal each other.*1578

*Let us see what we can do.*1586

*Let us go ahead and start with this one fist.*1588

*Let me go ahead and do this in blue actually.*1590

*This is number 1, this is number 2, this is number 3, and this is number 4.*1595

*Let us do number 1.*1603

*For n not equal to 0, here is what we have.*1606

*The integral from 0 to π of Z sub N D θ, that is actually going to equal the integral from 0 to 2 π.*1617

*Here is our function, it is going to be, I’m going to pull the 1/ 2π out.*1633

*I’m just going to go ahead and write that as a constant.*1641

*It is going to be 1/ √2π × the integral from 0 to 2π of e ⁺I n θ D θ,*1644

*That is equal to 1/ 2π under the radical × the integral from 0 to 2π of cos θ + I sin θ.*1661

*I’m sorry this is N θ.*1673

*Just represent this using Euler’s formula, cos n θ + I sin N θ.*1678

*This is of the integral operator, the integration is actually linear so I can separate these out.*1688

*It was actually going to equal 1/ √2π × the integral from 0 to 2π of cos n θ D θ + 1/ the integral from 0 to 2π.*1694

*I’m going to put this I, I’m going to pull I out also.*1718

*Sin N θ D θ and this is equal to, this is 0 to 2π of the cos N θ.*1723

*This is 0 and this is 0.*1733

*It ends up equaling 0 which is what we said we have to prove.*1737

*That takes care of the first integral.*1741

*The second integral for N = 0.*1745

*Let us see, for N =0, Z sub N θ =1/ 2π is going to be e⁰ which is going to equal 1/ 2π rad.*1750

*We are going to have the integral from 0 to 2π of 1/ √2 π D θ.*1779

*That is going to equal 2π/ √2π.*1793

*This is just 2π/ 2π ^½ = 2π¹/2 which is √2π.*1799

*That takes care of N=0.*1816

*Let us see, for N not = M.*1821

*We said that the complex conjugate is just 1/ √2Π × E ⁻I N Θ, with the negative sign there.*1832

*The integral from 0 to 2π of the Z* × Z D θ is going to equal 1/ 2π now the radical sign goes away because it is going to be 1/ √2π × 1/ √2 π.*1855

*I’m multiplying them.*1873

*The complex conjugate of this function, this is the complex conjugate.*1875

*We will just go ahead and do this as is.*1883

*We have E ⁺I N Θ × E ⁺I M Θ D Θ.*1886

*That is going to equal 1/ 2 Π OF E ⁺I × Θ × M – N D Θ.*1906

*M-m is just some integer.*1929

*Because m is an integer and n is an integer.*1940

*What you end up getting is 1/ 2 π × the integral from 0 to 2 π of E ⁺I let us just call it P θ.*1943

*This is just the same as the one that we did before.*1959

*This ends up being 1/ 2 π × the integral from 0, this is going to be cos P θ + I sin P θ Dθ.*1964

*That is just going to equal 0.*1986

*That takes care of that one.*1988

*For our final one, we want to show that 1n = m.*1992

*Therefore, we are going to get Z* × Z = E ⁻I N Θ × E ⁺I N Θ = E ⁺I Θ N-N = E⁰.*2003

*We are going to have this integral from 0 to 2 π Z* × Z D θ.*2032

*When n = m, it is nothing more than 1/ 2 π × the integral from 0 to 2 π D θ,*2041

*That just equals 2 π/ 2 π which equals 1.*2053

*Thank you so much for joining us here at www.educator.com.*2062

*We will see you next time, bye.*2064

1 answer

Last reply by: Professor Hovasapian

Sat Jun 27, 2015 5:58 PM

Post by Jinbin Chen on June 27, 2015

Hi, Mr. Raffi! Is differential equation a necessary prerequisite before viewing the quantum mechanics lectures in this series? I have had some exposure to multivariable calculus and linear algebra from your lecture series on this website (and I appreciate your enthusiasm in those videos, especially in linear algebra), but I am not sure if they are enough for quantum.

1 answer

Last reply by: Professor Hovasapian

Tue Mar 24, 2015 5:02 PM

Post by shashikanth sothuku on March 24, 2015

hi prof,

21i+8i = 29i at 8:00
