### Math Operations, Part 2

- In this lesson, we will go over the Math Module, Rational numbers, Complex numbers, Prime numbers, and Matrices
- The Math module contains methods for basic trignometric and logarithms
- It also defines constants PI and E
- Popular used Methods: cos, exp, log, log10, sin, sqrt, tan
- RDoc: http://www.ruby-doc.org/core-1.9.3/Math.html
- Rational Numbers are supported through the Rational class. They are numbers that can be expressed as a fraction of integers.
- Mathematical Ruby Scripts (mathn) is used in conjunction with the Math module to make mathematical operations better
- It pulls in other standard libraries and integrates them with the rest of Ruby's numeric class
- Complex Numbers represent a paired real number with an imaginary unit
- Prime Numbers are included in the mathn library. They generate prime numbers starting from 2.
- Matrices are represented through the Matrix class and provide methods for creating Matrices
- RDoc: http://www.ruby-doc.org/stdlib-1.9.3/libdoc/matrix/rdoc/Matrix.html

### Math Operations, Part 2

Lecture Slides are screen-captured images of important points in the lecture. Students can download and print out these lecture slide images to do practice problems as well as take notes while watching the lecture.

- Intro 0:00
- Math Operations 0:12
- Math Module
- Rational Numbers
- Complex Numbers
- Prime Numbers
- Matrices
- Math Module 1:12
- PI and E
- Math Module Methods 2:47
- atan2(x,y)
- cos(x)
- exp(x)
- Examples
- log(x)
- log(num, base)
- log10(x)
- sin(x)
- sqrt(x)
- tan(x)
- Math Functions: Part 1 of 3 8:12
- Math Functions: Part 2 of 3 9:32
- Math Functions: Part 3 of 3 10:19
- Math Module Rdoc
- Rational Numbers 13:23
- How to use
- Example
- Mathematical Ruby Scripts (Mathn) 16:25
- Example
- Complex Numbers 18:26
- polar
- rect
- Complex Number Examples 19:18
- Prime Numbers 20:14
- each(ubound=nil)
- prime?
- Example
- Matrices 23:15
- build(row_size, column_size=row_size)
- Example
- Matrix Rdoc

### Computer Science: Introduction to Ruby

I. Introduction to Ruby | ||
---|---|---|

Setting Up Your Environment | 22:08 | |

Intro to Ruby | 22:20 | |

Basic Tools for Using Ruby | 27:44 | |

Ruby Specifics | 20:45 | |

Ruby Data Types (Part 1) | 29:37 | |

Ruby Gems | 25:50 | |

Ruby Data Types (Part 2) | 40:24 | |

Objects | 1:05:46 | |

Loops | 38:54 | |

Strings | 28:30 | |

Regular Expressions | 33:27 | |

Arrays | 14:35 | |

Hashes | 27:48 | |

Math Operations, Part 1 | 28:47 | |

Math Operations, Part 2 | 28:51 | |

Dates and Times | 26:01 | |

Methods: Part 1 | 31:24 | |

Methods: Part 2 | 20:11 | |

Classes: Part I | 26:51 | |

Classes: Part II | 26:42 | |

Classes: Part III | 53:36 | |

Modules | 24:19 |

### Transcription: Math Operations, Part 2

*Welcome back to Educator.com.*0000

*Today's lesson is on math operations; this is the second part.*0002

*For today's lesson, we are going to go over five pieces that are part of math operations.*0010

*The first one we are going to look at is the Math module.*0019

*This has quite a bit of operations; most of the operations are related to the Math module, so I would give this a star.*0023

*After that, we are going to look at some of the math types.*0038

*One is the rational numbers, and after we look at rational numbers, we're going to look at complex numbers.*0045

*Then, prime numbers, and the last one we're going to look at is matrices, since they do have an object to create and manipulate matrices in Ruby.*0053

*First, let's look at the Math module.*0072

*This is a module that you can include in other objects; you can also use it by itself.*0077

*It has two constants as part of it: one is pi, and e.*0089

*To call it, you just call the Math::pi function, and the same with the e: you can just call it with Math::e.*0095

*The M is uppercase, and the three letters after it are lowercase.*0129

*That will get those two constant values.*0138

*The Math module contains a lot of methods for trigonometry and logarithms.*0143

*It can be invoked through the Math name space or included into scope.*0152

*Let's look at some of the methods.*0164

*The first one is atan2; it takes two arguments--in this case, we're giving it an x and a y.*0167

*This calculates the arc tangent, given the y and the x, which are these two values.*0178

*The next one is cosine; it uses the method cos; it takes one argument; and it calculates the cosine of x.*0188

*For our example here, all you do is to call the Math module directly; then, do the period, and call the method cos.*0199

*In this case, our argument is 0, and that comes up with the cosine 0, and the value is 0.*0211

*The next method we'll look at is this exponential function.*0219

*It uses exp, and this is e raised to the power of x, so it is equivalent to e ^{x}*0224

*For example, we have here the exponential to 1; e to the power of 1 is 2.7182, and it just keeps going down--81828459045.*0241

*We do call Math here, but you don't have to; you can include the Math module, and it will be part of your scope, and you can just call the function.*0262

*Let me show you how to do that.*0274

*For example, first, I'm going to do include math; and now I'm already in the Math scope, so I just need to pass the function in.*0279

*For example, before, I did math, log(1) and it gives me the value for the logarithm 1; I can just call log(1) now, and it does the exact same thing--since I included that Math module into my scope.*0292

*Also, I can call the new function we learned, the exponential function, to the power of 1, and I can call cosine and pass in 0, and it gives me a value of 1.0.*0306

*Actually, if that is the case, this is the wrong one; this is 1.0, as we just saw in that terminal.*0323

*The next one, as we just saw--we just looked at the logarithm function--you call log, and you pass the parameter x; this calculates the natural logarithm of x.*0338

*As we did in the terminal, math.log(1); you get 0.0.*0351

*You can also call the constant; in this case, we will do the constant for the e, math.e, and we pass the logarithm of that.*0357

*What is the natural logarithm of that value?--we get 2.7182, and it goes all the way down.*0369

*This logarithm function--we can actually pass two arguments in it; by default, it's going to do it as a base 10, but you can specify a second argument.*0379

*You can tell it specifically what base you want it to do.*0396

*This is the same as log, but the second argument specifies the base.*0401

*They also have another function that, if you are doing log10, it's going to default to, and you can actually specify that as a function.*0410

*I think this is made because it is so commonly used.*0419

*So, there is a function called log10; it takes one argument, x, and this calculates the base 10 logarithm of x.*0422

*Here, we can just call math.log10, pass in a value 1, and we get our value 0.0, our base 10 logarithm of x.*0430

*Again, the base 10 logarithm of 10 is 1.0.*0441

*There is also a function to calculate the sine of x.*0450

*Type sin, and pass in the parameter x.*0455

*You can also do square root and tangent: square root is sqrt, and it takes one argument of x; this returns a square root, and the value x must be positive.*0464

*You can also calculate the tangent with tan, and it takes one parameter.*0481

*There are quite a bit of functions; I have gathered a table, a list of them.*0491

*You can go through it and see all the different functions that you can use in this Math module.*0498

*I do have the bang value here; this bang value means that it will update the object it currently is and save it.*0506

*You also have the option to do the method directly, without the bang, which will create a new object with that new calculation.*0519

*There is arc cosine--you add an h; you have the hyperbolic arc cosine.*0529

*We already went through sine: you have arc sine, hyperbolic arc sine; arc tangent--this atan takes an x argument; atan2 takes two arguments, an x and a y argument.*0538

*You have atanh; this is the hyperbolic arc tangent.*0556

*This is the first page; there are a couple more here.*0565

*We already went over cosine; you can use the bang method with your cosine; if you add h, it will get you the hyperbolic cosine.*0569

*If you add sin, that calculates your sine.*0581

*There is an error function in math; do math.erf, and you can get the error function.*0587

*There is also a complementary error function with erfc.*0594

*You can calculate the base x of eular using method exp.*0601

*You can also calculate the normalized fraction exponent using frexp.*0609

*We are almost there; we are on our last page of functions.*0618

*You can calculate the hypotenuse using hypot; you can calculate the floating-point value that corresponds to the mantissa exponent using ldexp.*0622

*You have your sine calculations with sinh--you can calculate the hyperbolic sine; next is square root--sqrt does that--and your tangents--tan and tanh will do your hyperbolic tangent, with the addition of that h value.*0641

*Let's go ahead and look at the Math module.*0666

*If you look at the RDoc, you will notice that it has more examples about all these functions, too.*0670

*This is the Math module; notice that it has the two constants e and pi.*0681

*As we just went through that whole list, they do have it on here, too, with the cosine, cosh, sin, sinh...you can see the source for that, too, how it calculates it...*0692

*Notice also, here they tell you the arguments: some take one argument; some take two.*0703

*For the arc tangent, given x, it gives you some examples here.*0710

*You can take a look at that and see how they calculate that.*0717

*Actually, we didn't go over this one: there is a method for cube root: that is cbrt; it takes a parameter of numeric.*0726

*It returns a Float.*0738

*We already went through error: it "calculates the error function of x," and takes x--one parameter.*0743

*exp--e to the power of x--we went over that, and they give you some examples there, also.*0750

*There is a gamma function, and a logarithm gamma function, too.*0761

*As you see here, it's all our log functions that we went over: they overload it, where one has one argument, one has two arguments, one with a base value, and then there is one for log10...*0769

*There is actually one for base 2--log2, so that might be useful to you math calculators.*0778

*That is everything for that Math module.*0791

*That is the Math module; let's move on now to rational numbers.*0800

*Rational numbers: these are numbers that can be expressed as a fraction of integers.*0806

*Just integers; remember that; we are not doing Floats or decimal values; they are all like fractions, essentially; these are all fractions.*0813

*This is supported through the Rational class--remember that Rational class?--it will be useful in this case.*0826

*You must use Integers, not Floats.*0835

*To use this Rational number, you have to load in a couple of libraries.*0840

*The first library you are going to load is this require rational, and then you have to load require mathn.*0846

*We will go deeper into what this mathn library does; it's not required for rational numbers, but it's recommended, so I'm just going to say require that mathn library.*0854

*After you require those two libraries, then you can start using this Rational object.*0865

*For example, here I'm calling rational, and I'm putting my fraction in.*0872

*I put my fraction in: 4 out of 10; after I do that, I press Return, and it's going to automatically reduce down to 2 out of 5.*0877

*I can also do the same thing with 5 out of 10; pass that in, press Return, and it's going to reduce it down to 1 over 2.*0887

*Let's look at some more examples.*0896

*Here, I'm just going to do require.rational, and then I'm going to require mathn, and let's show you the 10 out of 20, and it reduces it down straight to 1 out of 2.*0901

*Rational 3 out of 4 gets me 3 out of 4; rational 1 out of 10--and let's do times 5--so we have 5 out of 10, and it reduces it to 1 out of 2.*0922

*Also, I can go over a whole number, and it does do 3 out of 2.*0939

*You can also do other functions; I can also do exponent, so I can do 1 out of 2 to the power of 2, and it will get me 1 out of 4.*0946

*I can also convert to Strings and Floats.*0957

*If I do Rational (1,4), and convert that to a string, it takes that whole value and puts quotes around it.*0960

*I can do the same thing with Float, and--look there!--it actually gives me the decimal value, .25.*0969

*That is rational numbers.*0984

*Let's look over that mathn library very quickly.*0985

*Mathn is a standard library; it's used for a lot of math functionalities; when used in conjunction with the Math module, it makes mathematical operations better.*0990

*That is just the gist of it; you use it when you are doing math operations; just require it.*1004

*It pulls in other standard libraries, and it integrates them with the rest of Ruby's numeric classes, so it's very useful, so definitely use this library.*1011

*I just gave you a very simple example here, but if I don't include this library and I did 1 out of 2, it will return 0.*1022

*That is not going to work for me; I want specific values.*1030

*If I require this mathn, 1 out of 2 will return 1 out of 2, because it's including these other standard libraries to help do calculations.*1035

*I can show you some examples: let's go ahead and start over and call IRB again--clean slate, nothing is loaded.*1043

*All we do here is, I just pass 1 out of 2, and it returns 0.*1053

*But if I do require.mathn, then I do 1 out of 2, and it gets me the correct answer.*1059

*I can also do calculations with the different functions: 1 out of 2 times 3 over 10--I get 3 over 20.*1071

*I can do a calculation with sqrt, and I get my complex value, with 0 and one imaginary number.*1079

*Next, let's look at complex numbers.*1103

*Complex numbers use the Complex class.*1106

*This is represented as a real number with an imaginary number; I just showed you a terminal view with that...so an example would be 0+1i.*1112

*There are two different types of complex numbers we can use: we can call this polar method, and it will return a complex object denoted in polar form, and I can also call rect, and that will return a complex object denoted in rectangular form.*1126

*You have polar and rectangular.*1148

*Here are some examples of complex numbers.*1156

*You just pass the Complex object, and you pass a parameter in.*1159

*I do Complex(1), and it's going to return me 1+0i.*1164

*You can also pass in a second parameter for imaginary numbers; so, if I call Complex(2,3), it's going to get 2+3i.*1171

*I can pass in these arguments into the rectangular or the polar method.*1180

*If I do Complex.rect and pass (2,3), it's going to get me 2+3i.*1187

*In the polar form, I pass (3,0); it's going to get 3.0+0.0i.*1195

*Here, it passes it in with the decimals; so it has some Float values there.*1201

*Next, let's look at the prime numbers.*1210

*This uses the Prime class.*1214

*It's included in the mathn library, and it starts generating prime numbers, starting from the value 2.*1218

*What is a prime number? It's a value that is divisible by 1 and itself.*1232

*Let's look at some methods.*1239

*One is this method called each: it takes one parameter--if you don't pass anything, it will default that parameter to nil.*1241

*I'm going to call ubound, which is an arbitrary positive number.*1251

*This is known as the upper bound of the enumeration.*1258

*With this method, you can output all the prime numbers to a certain bound, so once it goes over that, it will stop.*1262

*I'll show you an example of that.*1275

*The next one is this value called prime?, and this returns if the value is prime.*1279

*You call itself here, so this would be prime, and then you call the method prime?, and whatever number value you want to check.*1287

*This will return true or false.*1308

*Let's go through an example with the prime values.*1312

*I believe we already have mathn loaded.*1318

*Let's do an example: let's get all the prime numbers up to 10.*1324

*I do each, pass in value 10, and do prime, and then I'm going to output each one, and it starts from the value 2; the next prime number is 3; 5; and 7; it ends at 7--that is where we hit our bound of 10, so it doesn't go over that.*1332

*We can also show you the prime?--let's check: Is 2 prime? It says it is prime; 1 is false; 3 is prime; if I pass the value 4, it says it's false.*1360

*5 and 7 are true; they are prime.*1377

*OK, so those are prime numbers.*1387

*The last thing we want to look at is matrices.*1391

*Matrices are represented through the Matrix class.*1395

*This provides methods for creating matrices, plus manipulating and updating.*1400

*It requires loading the class beforehand.*1408

*For example, I'm going to show you the build method.*1413

*The build method for matrices has two arguments: you need to specify the row size and the column size.*1418

*If you don't specify the column size, it will default to the row size.*1427

*This creates a matrix of row size by column size.*1432

*For example, I call the build method, and I'm doing a row size of 2, and then I'm specifying a column size of 3.*1437

*I'm also passing a block in here; this block says what I'm going to initialize it to.*1459

*In this case, I'm saying to initialize it to 1.*1465

*It makes this new matrix that has values of 1 in it, row size 2, and column--3.*1469

*Let's go through the RDoc.*1482

*This is very basic, but let's go through the RDoc for it.*1490

*Here is the Matrix RDoc; there is quite a bit on methods here, actually.*1495

*"The Matrix class represents a mathematical matrix...provides methods for creating matrices, operating on them arithmetically and algebraically, and determining their mathematical properties."*1503

*I showed you the build method, but you will notice that there are quite a bit of methods to build matrices, using different methods: rows, columns, build, diagonal, scalar, identity, zero...*1517

*You can also access the properties of it with quite a bit of functions here: row_size, column_size, row, column, collect, map...*1530

*Properties of a matrix: you can check that, too--you can say, "Hey, is this matrix diagonal? Is it lower_triangular? Regular? Singular? Square?"*1541

*You can check these properties.*1551

*You can also do mathematical arithmetic with it, using multiplication, addition, subtraction, division, inverse, the exponent function...*1556

*You should have quite a bit of functions here to do whatever process you need to do.*1567

*You can use the eigen, the eigensystem, conjugate, imaginary, rectangular, complex arithmetic for the matrices...*1572

*You can also convert it to other types: you can use coerce, to_a, row_vectors, column_vectors.*1581

*You can do string representations with to_s and inspect.*1588

*There are attributes: you have your column_size, your rows...*1596

*If you go through here, you can see a lot of the methods: we went through build, and there are quite a bit of methods here.*1600

*You can create an empty matrix, just with the row_size and the column_size.*1607

*We already went over build, but notice, with build here, I can also pass in what row and column it's working on, so I can initialize values using that.*1612

*I can give it a dynamic value, as they do here: they say, "The value I'm going to pass in is column minus row."*1623

*Then, you have a bunch of instance methods to do matrix calculation.*1639

*You also have this each method as an enumerator, so you can grab elements by what part of the matrix you want.*1652

*You can get all the elements, the ones that are diagonal, strict_lower, strict_upper...*1660

*There are quite a bit of properties there.*1667

*You can also get the Hash code for that matrix...that is interesting.*1673

*You can also get the inverse of the matrix, using the inverse method.*1679

*As I said before, you can check "Is it lower_triangular?", and just say to the matrix, "Hey, are you lower_triangular?"--just call this method, and will say yes, it is, or it isn't--it's false.*1683

*There are quite a bit of functions here, so definitely look at the RDoc.*1699

*That will definitely go over a lot of different methods in the matrix, and help you manipulate, create new matrices, and update existing ones.*1705

*So, definitely go over that, and otherwise, that is the end of this lesson at Educator.com.*1718

*Hope to see you next time, and good luck on your Math module searches and processes!*1724

## Start Learning Now

Our free lessons will get you started (Adobe Flash

Sign up for Educator.com^{®}required).Get immediate access to our entire library.

## Membership Overview

Unlimited access to our entire library of courses.Learn at your own pace... anytime, anywhere!
