Autonomous Equations & Phase Plane Analysis

Slide Duration:

Table of Contents

Section 1: First-Order Equations
Linear Equations

1h 7m 21s

Intro
0:00
Lesson Objectives
0:19
How to Solve Linear Equations
2:54
Calculate the Integrating Factor
2:58
Changes the Left Side so We Can Integrate Both Sides
3:27
Solving Linear Equations
5:32
Further Notes
6:10
If P(x) is Negative
6:26
Leave Off the Constant
9:38
The C Is Important When Integrating Both Sides of the Equation
9:55
Example 1
10:29
Example 2
22:56
Example 3
36:12
Example 4
39:24
Example 5
44:10
Example 6
56:42
Separable Equations

35m 11s

Intro
0:00
Lesson Objectives
0:19
Some Equations Are Both Linear and Separable So You Can Use Either Technique to Solve Them
1:33
Important to Add C When You Do the Integration
2:27
Example 1
4:28
Example 2
10:45
Example 3
14:43
Example 4
19:21
Example 5
27:23
Slope & Direction Fields

1h 11m 36s

Intro
0:00
Lesson Objectives
0:20
If You Can Manipulate a Differential Equation Into a Certain Form, You Can Draw a Slope Field Also Known as a Direction Field
0:23
How You Do This
0:45
Solution Trajectories
2:49
Never Cross Each Other
3:44
General Solution to the Differential Equation
4:03
Use an Initial Condition to Find Which Solution Trajectory You Want
4:59
Example 1
6:52
Example 2
14:20
Example 3
26:36
Example 4
34:21
Example 5
46:09
Example 6
59:51
Applications, Modeling, & Word Problems of First-Order Equations

1h 5m 19s

Intro
0:00
Lesson Overview
0:38
Mixing
1:00
Population
2:49
Finance
3:22
Set Variables
4:39
Write Differential Equation
6:29
Solve It
10:54
Answer Questions
11:47
Example 1
13:29
Example 2
24:53
Example 3
32:13
Example 4
42:46
Example 5
55:05
Autonomous Equations & Phase Plane Analysis

1h 1m 20s

Intro
0:00
Lesson Overview
0:18
Autonomous Differential Equations Have the Form y' = f(x)
0:21
Phase Plane Analysis
0:48
y' < 0
2:56
y' > 0
3:04
If we Perturb the Equilibrium Solutions
5:51
Equilibrium Solutions
7:44
Solutions Will Return to Stable Equilibria
8:06
Solutions Will Tend Away From Unstable Equilibria
9:32
Semistable Equilibria
10:59
Example 1
11:43
Example 2
15:50
Example 3
28:27
Example 4
31:35
Example 5
43:03
Example 6
49:01
Section 2: Second-Order Equations
Distinct Roots of Second Order Equations

28m 44s

Intro
0:00
Lesson Overview
0:36
Linear Means
0:50
Second-Order
1:15
Homogeneous
1:30
Constant Coefficient
1:55
Solve the Characteristic Equation
2:33
Roots r1 and r2
3:43
To Find c1 and c2, Use Initial Conditions
4:50
Example 1
5:46
Example 2
8:20
Example 3
16:20
Example 4
18:26
Example 5
23:52
Complex Roots of Second Order Equations

31m 49s

Intro
0:00
Lesson Overview
0:15
Sometimes The Characteristic Equation Has Complex Roots
1:12
Example 1
3:21
Example 2
7:42
Example 3
15:25
Example 4
18:59
Example 5
27:52
Repeated Roots & Reduction of Order

43m 2s

Intro
0:00
Lesson Overview
0:23
If the Characteristic Equation Has a Double Root
1:46
Reduction of Order
3:10
Example 1
7:23
Example 2
9:20
Example 3
14:12
Example 4
31:49
Example 5
33:21
Undetermined Coefficients of Inhomogeneous Equations

50m 1s

Intro
0:00
Lesson Overview
0:11
Inhomogeneous Equation Means the Right Hand Side is Not 0 Anymore
0:21
First Solve the Homogeneous Equation
1:04
Find a Particular Solution to the Inhomogeneous Equation Using Undetermined Coefficients
2:03
g(t) vs. Guess for ypar
2:42
If Any Term of Your Guess for ypar Looks Like Any Term of yhom
5:07
Example 1
7:54
Example 2
15:25
Example 3
23:45
Example 4
33:35
Example 5
42:57
Inhomogeneous Equations: Variation of Parameters

49m 22s

Intro
0:00
Lesson Overview
0:31
Inhomogeneous vs. Homogeneous
0:47
First Solve the Homogeneous Equation
1:17
Notice There is No Coefficient in Front of y''
1:27
Find a Particular Solution to the Inhomogeneous Equation Using Variation of Parameters
2:32
How to Solve
4:33
Hint on Solving the System
5:23
Example 1
7:27
Example 2
17:46
Example 3
23:14
Example 4
31:49
Example 5
36:00
Section 3: Series Solutions
Review of Power Series

57m 38s

Intro
0:00
Lesson Overview
0:36
Taylor Series Expansion
0:37
Maclaurin Series
2:36
Common Maclaurin Series to Remember From Calculus
3:35
Radius of Convergence
7:58
Ratio Test
12:05
Example 1
15:18
Example 2
20:02
Example 3
27:32
Example 4
39:33
Example 5
45:42
Series Solutions Near an Ordinary Point

1h 20m 28s

Intro
0:00
Lesson Overview
0:49
Guess a Power Series Solution and Calculate Its Derivatives, Example 1
1:03
Guess a Power Series Solution and Calculate Its Derivatives, Example 2
3:14
Combine the Series
5:00
Match Exponents on x By Shifting Indices
5:11
Match Starting Indices By Pulling Out Initial Terms
5:51
Find a Recurrence Relation on the Coefficients
7:09
Example 1
7:46
Example 2
19:10
Example 3
29:57
Example 4
41:46
Example 5
57:23
Example 6
1:09:12
Euler Equations

24m 42s

Intro
0:00
Lesson Overview
0:11
Euler Equation
0:15
Real, Distinct Roots
2:22
Real, Repeated Roots
2:37
Complex Roots
2:49
Example 1
3:51
Example 2
6:20
Example 3
8:27
Example 4
13:04
Example 5
15:31
Example 6
18:31
Series Solutions

1h 26m 17s

Intro
0:00
Lesson Overview
0:13
Singular Point
1:17
Definition: Pole of Order n
1:58
Pole Of Order n
2:04
Regular Singular Point
3:25
Solving Around Regular Singular Points
7:08
Indical Equation
7:30
If the Difference Between the Roots is An Integer
8:06
If the Difference Between the Roots is Not An Integer
8:29
Example 1
8:47
Example 2
14:57
Example 3
25:40
Example 4
47:23
Example 5
1:09:01
Section 4: Laplace Transform
Laplace Transforms

41m 52s

Intro
0:00
Lesson Overview
0:09
Laplace Transform of a Function f(t)
0:18
Laplace Transform is Linear
1:04
Example 1
1:43
Example 2
18:30
Example 3
22:06
Example 4
28:27
Example 5
33:54
Inverse Laplace Transforms

47m 5s

Intro
0:00
Lesson Overview
0:09
Laplace Transform L{f}
0:13
Run Partial Fractions
0:24
Common Laplace Transforms
1:20
Example 1
3:24
Example 2
9:55
Example 3
14:49
Example 4
22:03
Example 5
33:51
Laplace Transform Initial Value Problems

45m 15s

Intro
0:00
Lesson Overview
0:12
Start With Initial Value Problem
0:14
Take the Laplace Transform of Both Sides of the Differential Equation
0:37
Plug in the Identities
1:20
Take the Inverse Laplace Transform to Find y
2:40
Example 1
4:15
Example 2
11:30
Example 3
17:59
Example 4
24:51
Example 5
36:05
Section 5: Review of Linear Algebra
Review of Linear Algebra

57m 30s

Intro
0:00
Lesson Overview
0:41
Matrix
0:54
Determinants
4:45
3x3 Determinants
5:08
Eigenvalues and Eigenvectors
7:01
Eigenvector
7:48
Eigenvalue
7:54
Lesson Overview
8:17
Characteristic Polynomial
8:47
Find Corresponding Eigenvector
9:03
Example 1
10:19
Example 2
16:49
Example 3
20:52
Example 4
25:34
Example 5
35:05
Section 6: Systems of Equations
Distinct Real Eigenvalues

59m 26s

Intro
0:00
Lesson Overview
1:11
How to Solve Systems
2:48
Find the Eigenvalues and Their Corresponding Eigenvectors
2:50
General Solution
4:30
Use Initial Conditions to Find c1 and c2
4:57
Graphing the Solutions
5:20
Solution Trajectories Tend Towards 0 or ∞ Depending on Whether r1 or r2 are Positive or Negative
6:35
Solution Trajectories Tend Towards the Axis Spanned by the Eigenvector Corresponding to the Larger Eigenvalue
7:27
Example 1
9:05
Example 2
21:06
Example 3
26:38
Example 4
36:40
Example 5
43:26
Example 6
51:33
Complex Eigenvalues

1h 3m 54s

Intro
0:00
Lesson Overview
0:47
Recall That to Solve the System of Linear Differential Equations, We find the Eigenvalues and Eigenvectors
0:52
If the Eigenvalues are Complex, Then They Will Occur in Conjugate Pairs
1:13
Expanding Complex Solutions
2:55
Euler's Formula
2:56
Multiply This Into the Eigenvector, and Separate Into Real and Imaginary Parts
1:18
Graphing Solutions From Complex Eigenvalues
5:34
Example 1
9:03
Example 2
20:48
Example 3
28:34
Example 4
41:28
Example 5
51:21
Repeated Eigenvalues

45m 17s

Intro
0:00
Lesson Overview
0:44
If the Characteristic Equation Has a Repeated Root, Then We First Find the Corresponding Eigenvector
1:14
Find the Generalized Eigenvector
1:25
Solutions from Repeated Eigenvalues
2:22
Form the Two Principal Solutions and the Two General Solution
2:23
Use Initial Conditions to Solve for c1 and c2
3:41
Graphing the Solutions
3:53
Example 1
8:10
Example 2
16:24
Example 3
23:25
Example 4
31:04
Example 5
38:17
Section 7: Inhomogeneous Systems
Undetermined Coefficients for Inhomogeneous Systems

43m 37s

Intro
0:00
Lesson Overview
0:35
First Solve the Corresponding Homogeneous System x'=Ax
0:37
Solving the Inhomogeneous System
2:32
Look for a Single Particular Solution xpar to the Inhomogeneous System
2:36
Plug the Guess Into the System and Solve for the Coefficients
3:27
Add the Homogeneous Solution and the Particular Solution to Get the General Solution
3:52
Example 1
4:49
Example 2
9:30
Example 3
15:54
Example 4
20:39
Example 5
29:43
Example 6
37:41
Variation of Parameters for Inhomogeneous Systems

1h 8m 12s

Intro
0:00
Lesson Overview
0:37
Find Two Solutions to the Homogeneous System
2:04
Look for a Single Particular Solution xpar to the inhomogeneous system as follows
2:59
Solutions by Variation of Parameters
3:35
General Solution and Matrix Inversion
6:35
General Solution
6:41
Hint for Finding Ψ-1
6:58
Example 1
8:13
Example 2
16:23
Example 3
32:23
Example 4
37:34
Example 5
49:00
Section 8: Numerical Techniques
Euler's Method

45m 30s

Intro
0:00
Lesson Overview
0:32
Euler's Method is a Way to Find Numerical Approximations for Initial Value Problems That We Cannot Solve Analytically
0:34
Based on Drawing Lines Along Slopes in a Direction Field
1:18
Formulas for Euler's Method
1:57
Example 1
4:47
Example 2
14:45
Example 3
24:03
Example 4
33:01
Example 5
37:55
Runge-Kutta & The Improved Euler Method

41m 4s

Intro
0:00
Lesson Overview
0:43
Runge-Kutta is Know as the Improved Euler Method
0:46
More Sophisticated Than Euler's Method
1:09
It is the Fundamental Algorithm Used in Most Professional Software to Solve Differential Equations
1:16
Order 2 Runge-Kutta Algorithm
1:45
Runge-Kutta Order 2 Algorithm
2:09
Example 1
4:57
Example 2
10:57
Example 3
19:45
Example 4
24:35
Example 5
31:39
Section 9: Partial Differential Equations
Review of Partial Derivatives

38m 22s

Intro
0:00
Lesson Overview
1:04
Partial Derivative of u with respect to x
1:37
Geometrically, ux Represents the Slope As You Walk in the x-direction on the Surface
2:47
Computing Partial Derivatives
3:46
Algebraically, to Find ux You Treat The Other Variable t as a Constant and Take the Derivative with Respect to x
3:49
Second Partial Derivatives
4:16
Clairaut's Theorem Says that the Two 'Mixed Partials' Are Always Equal
5:21
Example 1
5:34
Example 2
7:40
Example 3
11:17
Example 4
14:23
Example 5
31:55
The Heat Equation

44m 40s

Intro
0:00
Lesson Overview
0:28
Partial Differential Equation
0:33
Most Common Ones
1:17
Boundary Value Problem
1:41
Common Partial Differential Equations
3:41
Heat Equation
4:04
Wave Equation
5:44
Laplace's Equation
7:50
Example 1
8:35
Example 2
14:21
Example 3
21:04
Example 4
25:54
Example 5
35:12
Separation of Variables

57m 44s

Intro
0:00
Lesson Overview
0:26
Separation of Variables is a Technique for Solving Some Partial Differential Equations
0:29
Separation of Variables
2:35
Try to Separate the Variables
2:38
If You Can, Then Both Sides Must Be Constant
2:52
Reorganize These Intro Two Ordinary Differential Equations
3:05
Example 1
4:41
Example 2
11:06
Example 3
18:30
Example 4
25:49
Example 5
32:53
Fourier Series

1h 24m 33s

Intro
0:00
Lesson Overview
0:38
Fourier Series
0:42
Find the Fourier Coefficients by the Formulas
2:05
Notes on Fourier Series
3:34
Formula Simplifies
3:35
Function Must be Periodic
4:23
Even and Odd Functions
5:37
Definition
5:45
Examples
6:03
Even and Odd Functions and Fourier Series
9:47
If f is Even
9:52
If f is Odd
11:29
Extending Functions
12:46
If We Want a Cosine Series
14:13
If We Wants a Sine Series
15:20
Example 1
17:39
Example 2
43:23
Example 3
51:14
Example 4
1:01:52
Example 5
1:11:53
Solution of the Heat Equation

47m 41s

Intro
0:00
Lesson Overview
0:22
Solving the Heat Equation
1:03
Procedure for the Heat Equation
3:29
Extend So That its Fourier Series Will Have Only Sines
3:57
Find the Fourier Series for f(x)
4:19
Example 1
5:21
Example 2
8:08
Example 3
17:42
Example 4
25:13
Example 5
28:53
Example 6
42:22
Loading...
This is a quick preview of the lesson. For full access, please Log In or Sign up.
For more information, please see full course syllabus of Differential Equations
Bookmark & Share Embed

Share this knowledge with your friends!

Copy & Paste this embed code into your website’s HTML

Please ensure that your website editor is in text mode when you paste the code.
(In Wordpress, the mode button is on the top right corner.)
  ×
  • - Allow users to view the embedded video in full-size.
Since this lesson is not free, only the preview will appear on your website.
  • Discussion

  • Answer Engine

  • Study Guides

  • Download Lecture Slides

  • Table of Contents

  • Transcription

  • Related Books

Lecture Comments (10)

1 answer

Last reply by: Dr. William Murray
Mon Mar 7, 2016 9:41 AM

Post by David Löfqvist on March 6, 2016

Hi! Great lecture, and yes I would also love to see more topics, but that's not my reason for commenting. I'm wondering if you could give some physical example of a semistable equalibrium?

5 answers

Last reply by: Dr. William Murray
Fri Oct 30, 2015 4:13 PM

Post by Agustin Velasquez on September 13, 2014

Awesome lecture , it really helped me grasp a better understanding of autonomous equations. However, in my class we,ve now moved to exact equations and integrating factors. is there any chance a lesson can be done on these two topics? thanks

1 answer

Last reply by: Dr. William Murray
Thu Jul 18, 2013 8:32 AM

Post by mateusz marciniak on July 7, 2013

hi professor great lecture, i'm very glad there are still great professor's out there such as yourself who know exactly how to teach, i'm very grateful. i have one question though, when we make our phase diagrams i don't know how to tell when our polynomial is positive or negative which would change the orientation of my graph. for example when we did example 5 i didn't know which way to orient the cubic function. Thanks

Autonomous Equations & Phase Plane Analysis

Autonomous Equations and Phase Plane Analysis (PDF)

Autonomous Equations & Phase Plane Analysis

Lecture Slides are screen-captured images of important points in the lecture. Students can download and print out these lecture slide images to do practice problems as well as take notes while watching the lecture.

  • Intro 0:00
  • Lesson Overview 0:18
    • Autonomous Differential Equations Have the Form y' = f(x)
    • Phase Plane Analysis
    • y' < 0
    • y' > 0
    • If we Perturb the Equilibrium Solutions
    • Equilibrium Solutions
    • Solutions Will Return to Stable Equilibria
    • Solutions Will Tend Away From Unstable Equilibria
    • Semistable Equilibria
  • Example 1 11:43
  • Example 2 15:50
  • Example 3 28:27
  • Example 4 31:35
  • Example 5 43:03
  • Example 6 49:01

Transcription: Autonomous Equations & Phase Plane Analysis

Hi welcome back to www.educator.com we are working on differential equations my name is Will Murray and today we are going to look at autonomous equations.0000

And we are going to use what is called phase plane analysis to study them so of course i need to tell you what all those words mean so let us go ahead and get started here a little lesson overview.0009

Autonomous differential equations the idea there is that you can write the equation in a form y′ is equal to some function just of y that is the real key here is on the right hand side you only see a y and so you do not see the other variable if you are talking about x or t.0020

The key thing is that you just have y′ is equal to some function of y, no access or t is on the right hand side.0040

And so we have a special way of understanding those which is that we are going to graph y′ versus y so were going to set up a set of axis.0047

And we will have y here and y′ here now these graphs are very different from the slope fields that we studied earlier and the solutions that we graph earlier, so do not get these graphs these phase plane graphs mixed up with the slope field graphs.0061

Before when we studied slope fields we will have either x or t on the horizontal axis and we will have y on the vertical axis and we are changing this now we have y on the horizontal axis and y′ on the vertical axis.0080

So very important difference here, this are totally different graphs from what we have seen before and we are going to study this graphs using what is known as phase plane analysis.0099

What we are going to have is a graph of f(y)and so we have something like this when we graph f(y).0111

And the point here is that we can look at these and we can see what values of y make y′ be positive or negative or zero and then that can tell us weather our solutions are sloping upwards or downwards or weather they are horizontal so that is the whole point here.0126

Let me give you a quick idea of that, in this case ok show this in red down here we have y′ is less than zero, up here we have y′ positive, down here we have y′ less than 0 and up here we have y′ is greater than 0.0148

And so if we translate that into the shape of our actual solutions anytime we see y′ less than 0 we know we have solutions that have a negative slopes so their tending downwards.0169

Anytime we see y′ greater than 0 we know we have solutions that tend upwards so let me try to draw what these solutions would look like I'm going to make myself a little space here and draw some graphs to illustrate this phase plane analysis so i save 3 places there where that y that f(y) crosses the y axis.0184

Now I'm going to put y on the vertical axis and i will put t on the horizontal axis where x if that is another variable so here are those places where y′ where f(y) crossed the 0 mark there.0223

And what this tells us is that down here before you get to the first place maybe a column A, B and C.0248

Here is A, B and C when y is less than A we see negative values for y′, y′ was less than 0 which means we have curves that are sloping downhill.0258

So I'm going to draw negative slopes down here in between A and B we see that y′ is greater than 0 so how curves sloping uphill.0272

So there is solutions that slope uphill because i know they have a positive derivative y′ is positive.0294

Between B and C, y′ is less than 0 so my solutions between B and C are sloping downhill again.0301

I'm making them webel of because I know the solution curves do not cross each other and then bigger than C, I have y′ greater than 0 so I have these solutions that slope up again.0311

So that phase plane analysis helps me draw the solution curves in the plain in the y-t plane without even actually solving the different equation.0329

So this is a really powerful technique here let us investigate this a little further so let me draw those that phase plane again so you can see how that played out.0343

So here is the original craft that we started with and here is the place where it crosses 0 the 3 places where it crosses 0.0358

So this was remember graphing y′ versus y and then that translated into a graph of our solution curves when we graph y versus either t or x or whatever the other variable is i call it t.0374

And so we have this 3 places corresponding to A, B and C where f(y) is 0 so in between those we figured out that below A and between B and C we have solution curves where y′ is negative so they are is sloping downhill.0392

So below A and between B and C they are sloping downhill and then in the other regions between A and B, y′ is positive because f(y) was positive this is y′ greater than 0, y′ is greater than 0 that is bigger than C so solution curves positive here.0426

And here y′ is less than 0, y′ is less than 0 that corresponds to the 2 regions over here where the solution curves are going downhill and then right on the boarder line is those places actually at A, B and C here where y′ is equal to 0.0450

So we have some stable solutions where y′ is equal to 0 and those are called equilibrium solutions that means the solution just stays completely horizontal it never goes up or down so those are called the equilibrium solutions.0471

So in these example we have 3 equilibrium solutions well this are more samples later on with more specific numbers i just kinda wanted to give you the general overview of the possible things that can happen and then will get down to details later on.0488

So the question where often ask is if we perturb the equilibrium solutions that means if we started one of this equilibrium solutions and maybe bump it a little bit; bump it up or bump it down which ones will actually return to equilibrium?0503

So let me give you an example of this if we start at B here and we suddenly bump up a little bit notice that we get forced back down to B or if we bump it down little bit we get forced back up to B.0520

So that means B is known as a stable equilibrium and the way you can identify that looking back at the phase plane is that y′ is going downwards because when your below it y′ is positive when your above the y′ is negative.0540

That means either way you get bumped you are going to go back towards that equilibrium solution at y = B.0561

Now on the other side of that look is at what happens if we start at C and then we got bumped a little all of the sudden we get knock down to the solution to that tree they goes far away from C or if we get bumped a little bit down we get knock down to the solution to that tree that again goes far away from C.0570

So C is considered to be an unstable equilibrium even though if you stay exactly at C you will never deviate from that path if you get bumped a little bit away from C you get bumped to an solution which takes you farther and farther away from C so that is considered to be an unstable equilibrium.0593

And we could have identified that back in the phase plane by seeing that y′ is going upwards that means that if you are a little bit smaller than C the curves are going down away from C if you are little bit bigger than C the curves are going up away from C.0614

So notice that A is the same way y′ is going upwards to that 0 at A so if again if you start at A and you get bumped a little bit you are going to go far away from A.0633

The solution curves are tending to run away from A so A is an unstable equilibrium and there is one sort of mix case here which is semi stable equilibrium.0651

i do not have an example of that in my picture here but a semi stable equilibrium is one where there is stable on one side so the solution curves are approaching it and they are unstable on the other side0662

So if it gets bumped, if it gets bumped one way say down here it would return to the equilibrium but if it gets bumped up it would go far away from the equilibrium.0676

So that is called a semi stable equilibrium and we will see an example of that later as we get in to some more specifics so i definitely think we are overdue to see an example here and actually work it out with some numbers.0690

So starting with the differential equation y′ is equal to y x y - 1 x 2 - y so what makes this autonomous differential equation is that there is no other variable on the right hand side except for y so in particular there is no x or t on the right hand side there is just y's.0706

So we are going to draw a graph of y′ versus y we are going to draw our phase plane and then we are going to the identify the equilibrium solutions.0729

So to draw our graph of y′ versus y that just means we are trying to graph this polynomial y x y - 1 x 2 - y so here is y and here is y′ and that polynomial is already nicely factored here.0740

So we know that if 0 when y is 0 and 1 and 2 that is because this tells you that if 0 and y is 0 this tells you that if 0 when y is 1 and this tells you that if 0 when y is 2 and notice that if you multiply this all together what you get is a cubic equation because we got 3 powers of y here.0758

So you get a cubic equation and the first coefficient will be negative that is because of this negative right here would make that first coefficient of the y cube be negative.0794

So there is one of 2 general shapes for cubic equation it can have this upwards curve or it can have it downwards curve and because of this - we know we got a downwards curve here.0807

So i am going to draw my f(y) as a downwards cubic there and of course if you want to confirm this it is easy to pull out a graphing calculator and just graph.0820

Just graph (f)y = y x y - 1 x 2 - y and you will see that it does not did look like this curve and then from that we want to identify the equilibrium solutions.0844

So that means the solutions where y′ is equal to 0 so those equilibrium solutions are exactly where this curve crosses 0 and so there they are at y = 0, 1 and 2 and so if you wanna graph those solutions.0861

Remember now this is a graph of y versus t it is not y′ versus y anymore we have here graphing y versus t so the equilibrium solutions come when y = 0 or 1 or 2 so i draw in my equilibrium solutions there to 1 and 0.0887

So those are my 3 equilibrium solutions we got those by looking at the graph of y′ versus y and figuring out where it crosses 0 each time.0917

Those tell us where y′ is 0 which means that the solutions for y will be completely horizontal their slope will be 0.0931

So I'm going to keep working with this example with this equation and the following example, so we are going to going with this.0941

We have the same differential equation y′ = y x y - 1 x 2 - y and we have 3 tasks here we are going to sketch other solutions.0950

We are going to label each one of the equilibrium solutions as stable and semi stable or unstable and then we are going to predict y of infinity predict a long term behaviour of this solutions for a bunch of real life initial conditions.0962

So we will see what would happen if we started at each of these initial points so I'm going to go to a new slide we will have more space but i will keep the equations here.0979

So this is the same differential equation y′ = y x y - 1 x 2 - y so let me just remind you how the phase plane analysis work for that.01642 We graphed y′ versus y here so there is y, 0, 1, and 2 and we graph y′ here so that was a downward cubic curve.0991

And then that translated into finding the equilibrium solutions on the graph of y versus t be very careful to keep these two graph straight it is really easy to confuse them.1026

One is y′ versus y so y is on the horizontal axis and then over here we have y versus t so y on the vertical axis.1044

So these equilibrium solutions at 0, 1, and 2 on the y axis those turn into values on the vertical axis over here and those give us horizontal equilibrium solutions.1054

So what we have to do now is sketch other solutions by looking back at the phase plane we can figure out here y′ is less sorry greater than 0 because it is above the horizontal axis here.1080

That tells us that when back here in this range where y is greater than 0 let me put some scales here 0, 1, and 2 when y is less than 0 that is down here we are going to see positive slopes.1099

So I'm going to draw some solution curves with positive slopes here in between 0 and 1 when y is in between 0 and 1 we see y′ is less than 0 so I'm going to draw some curves with negative slopes here.1114

Negative slopes in between y = 1 and y = 2 we see y′ is positive again so i will draw in some solution curves in between 1 and 2 with positive slopes.1133

And then when y gets up to be bigger than 2 we see that y′ < 0 again so i will draw a curves with negative slopes.01149

So from looking at the way the other solution curves behave we can tell which of our equilibrium solutions are stable and unstable.1163

if we look at y = 2 here then the solution curves are all tending towards y = 2 which means if you are at y = 2 and you got perturb a little bit if you got bump a little bit draw a little bump here you will and up going to y = 2 so that is a stable equilibrium.1173

Now here at the equilibrium here y = 1 and you got bump a little bit you would become part of the solution curve which goes away from y = 1 so that is an unstable equilibrium.1200

And finally if you are at y = 0 and maybe you got bump a little bit you are going to end up going back towards y = 0 so that is also a stable equilibrium.1218

And remember we said we could look at the phase plane analysis and have predicted that anytime the curve is going downwards through the axis it is a stable equilibrium.1233

So that means y = 0 and y = 2 are both stable equilibria and then when it is going upwards through the axis like here y = 1 it is an unstable equilibrium.1250

Now last we are supposed to do with this problem is to identify the long term behaviour if we started this different initial conditions.1265

So let me label this 1, 2, 3, and 4 so y have 2 = 5 that means we should have started the point at t = 2 and y = 5.1275

So i did not put a scale on my t axis for it does not really matter because the important thing here is that y is starting somewhere way up here at 5 let me put this in blue.1293

And you can see that any solution up here is going to tend downwards towards y approaching 2 so let me write that down.1305

So as y gets very large here y would as t goes to infinity y would approach 2 so that is that first initial condition.1319

The second initial condition says y(1) = 3 halfs so that means we are starting at 3 t = 1 and 3 halfses between 1 and 2 so maybe somewhere here.1339

And so we can see that this solution curve also goes up and approaches the equilibrium solutions at y = 2 so y(t) goes to infinity while very large values of t there will also go to 2.1352

Now so that was the 2nd initial condition we are given y(3) = 1 that means t = 3 we are starting exactly at y = 1 now that would mean we will continue exactly along that equilibrium solution.1373

So y(t) going to infinity would approach 1 now that is a sort of a theoretical answer and i have to qualify a little bit remember that 1 is unstable.1396

So in real life it is essentially never going to happen that anything will come to rest that are unstable equilibrium.1419

Everything is always getting bumped or jazzled or perturbed a little bit so in real life you would not ever expect to see a solution come to rest at an unstable equilibrium.1427

in real life it would at some point get bumped or jazzled or perturbed and it would go either or way up to 2 or a way down to 1 it would approach, I'm sorry, down to 0. It would approach the stable equilibria at 0 or at 2.1445

So in sort of a theoretical abstract perfect mathematical world it would keep going forever along this equilibrium at 1 in real life when everything gets bumped or jazzled a little bit by some kind of external forces it would actually tend away from 1.1474

And it would tend towards the stable equilibrium at 2 or the stable equilibrium down at 0 so that is kind of the most complicated case there.1494

Last case here is y(2) = -6 so that means t is 2 and y is somewhere down here at negative 6 and we can see that all the solution to that trace at this starting down here tend upwards and then they level off in your t = 0 or in your y = 0 so y as t goes to infinity would approach 0.1504

So let us just recap what we did there first we graphed y′ versus y we got this phase plane analysis which was very instrumental on sort of understanding everything that came later on.1532

So we graph this function y x y 1 x 2 - y and we got this downward cubic and then we used that to get all the information about the solution to the differential equation.1546

We never actually solve the differential equation here and often times with autonomous differential equation you do not have to.1561

Because you can learn what you need to just from looking at the phase plane so here by looking at this phase plane we see the places where it crosses 0 and we know that those correspond to this equilibrium solutions all did actual differential equation.1567

So these 3 places where it crosses 0 correspond to horizontal equilibrium solutions to the differential equation and then when we look at a little more detail we can see where y′ is positive and negative and positive and negative.1586

And we can translate that into the solution through that trace is positive, negative, positive and negative meaning that they are slope uphill or downhill, uphill or downhill.1607

And so those give us the solution through that trace to predict the sort of qualitative behaviour starting at any initial condition and so finally what we did here was we took 4 initial conditions to 5 and one 3 halfs and three 1 and two -61621

And then we started at each of those initial conditions and we saw where the solutions through that trace ended up.1643

So the one starting up here would go down and level of in your y = 2 this one down here would approach upwards y = 2 and then the most interesting one or the most complicated one is the that starts y = 1.1654

Because in the mathematically perfect world it would just stay at y=1 but in real life what would happen is it will get perturbed a little bit up or down and so it will end up at one of these stable equilibria you would never stay at an unstable equilibrium.1670

And finally y(2) = -6 that was the one that started down here and so we can see to that grows and approaches the stable equilibrium at y=0.1691

So we are going to practice this a few more times with some more examples we have a differential equation for example 3 here is y - 1^2 x y - 2 x y - 3 and again we are going to start out by drawing a graph of y′ versus y.1705

And then we are going to try to identify the equilibrium solutions so i will start out with y′ versus y and here is y on the horizontal axis and where else put y on the horizontal axis for this phase plane analysis.1722

And i see that i have a fourth degree equation here because it is y^2 here and then 2 more powers of y and i see that has zeros at 1 and 2 and 3.1743

And i see that that is going to be a positively oriented fourth degree equation it is going to be a positive value of y to the 4 which means it is going to be going to infinity.1761

Let me draw those in blue it is going to be going to an to positive infinity as y goes to positive or negative infinity so i know it is going up as it goes to positive or negative infinity y is 3 when y is 3 it crosses through the axis.1777

So there it is crossing there i will make route a little more visible there it crosses again at 2 and at 1 we have a double route which means it just barely touches the axis it is just tangent right there.1800

So that is how we can graph y′ versus y of course if you wanted to use graphing calculator that is no problem you just take this equation and throw that into your calculator and you will generate the same graph.1827

And then we want to identify the equilibrium solutions remember the equilibrium solutions are wherever this function crosses the y axis so here we got 3 equilibrium solutions at y = 1 at y = 2 and at y = 3 those are the values of y.1840

Then if you plug them in would give you′ is equal to 0 so when we draw the actual solutions on the next page those will be a horizontal lines.1868

The next example is actually a follow up with the same equation so I'm going to go ahead and keep moving with next example we will draw the equilibrium solutions and we will see how the other solutions behave.1881

So example 4 here same equation y′ is equal to y - 1^2 x y - 2 x y - 3 while we are being ask to do a sketch other solutions label each of those equilibrium solutions remember we had already identified those as y = 1, 2, and 3.1896

We are going to label each one of those a stable, semi stable or unstable and then we are going to predict the long term behaviour y of infinity for a couple of initial conditions here.1918

So i have got this information copy on to the next slide same differential equation here and we have already draw the graph of the phase plane here.1930

So let me recap that for you remember the phase plane has y′ on the vertical axis and y on the horizontal axis and we know that this one crosses 0 at 1, 2, and 3 those are the equilibrium solutions.1942

And we figured out on the previous examples you can go back and check that out if you do not remember how that works that it just barely touches 0 at y = 1 goes up comes down again and it goes of to positive infinity so we got these 3 equilibrium solutions.1960

And let me draw those and then we will try to figure out the behaviour of other solutions so now I'm actually drawing the solutions this is not the phase plane anymore so notice that y is on the vertical axis now back on the phase plane the y is on the horizontal axis.1990

So now my t is on my horizontal axis and I'm going to draw those equilibrium solutions at y = 1, 2, and 3 that was supposed to be a 3 so each one of those is going to be an equilibrium solution let me draw those in 1, 2, 3.2008

Equilibrium solution means y′ is 0 means your slope is 0 that is why you get horizontal lines thats what an equilibrium solution means and then we wanna identify how the other solutions play in between those solutions.2034

So in order to do that let us go back and look at phase plane remember we are not solving the differential equations everything we are doing in these lecture has to do with the phase plane analysis and just using that phase plane to figured out the shape of solutions without solving the differential equations.2050

So if go back and look at this i see the curve is positive here y′ is greater than 0, here y′ is still positive, here y′ is negative and here y′ is positive again.2069

So what that means is that when y is less than 1 over here I'm going to see positive slopes so over in the actual graph of the solutions less than 1 I'm going to see positive slopes here.2085

So I'm going to draw solution curves with positive slopes and now when y is between 1 and 2 i see that y′ is still positive so I'm going to draw some more positive slopes in between 1 and 2.2101

So y′ is positive derivative is positive means you are going to see uphill curves here between 1 and 2 now between 2 and 3 when y is between 2 and 3 i see that y′ is less than 0 it is negative which means I'm going to see downward slopes here.2125

And then finally when y is bigger than 3 I'm going to see positive slopes so i will some positive slopes here and then this is the only informations i need to identify which of the equilibrium equations are stable and unstable.02148

So if i look at this, if you look at this solution at y = 3 you see that the solution curves are tending away from it that means if you bumped in a little bit you would and up running far away from that solution so y = 3 is an unstable equilibrium there.2173

Y = 2 if you bumped a little bit away from that one the solution curves are coming back to get closer to it so the solution curves are approaching to it as a stable equilibrium.2194

And then at y = 1 thats sort of the most interesting case here because the solution curves on one side are tending away from it.2207

So if you bumped it a little bit up you will run away from this solution but if you bumped it a little bit down you would tend back towards the solution so that is a semi stable equilibrium.2215

So what we have done here is figured out how each one of these equilibria behave in the sense of if you bumped it a little bit will you go back towards the equilibrium or run far away from the equilibrium.2234

And as before we could have notice that just by looking back at the phase plane let me start with 2 here we see that y′ is going downwards through the axis so that was a stable equilibrium.2248

Over here at y = 3 it is going upwards through the axis so that is an unstable equilibrium and at y = 1 it is sort of a not doing either 1 it is that special case that goes down and just barely touches the axis and then rans away again so that is a semi stable equilibrium.2266

So finally we are ask about a couple of initial conditions here y(0) = 4 that means you would start at 0 and 4 and wanna figured when you had and up so let me look at the point 0, 4.2294

So that is somewhere up about here and we can see that up here whenever y is bigger that 3 we are in the region of positive slopes, we are in the region of sloping uphill so this first initial condition here would have, would give us the solutions that slopes upwards to positive infinity.2312

This second solution y(0) = 1/2 that means we start at t = 0 y is equal to 1/2 so 0 1/2 would be right here you see that this curves around there slope upwards and so for that one as t goes to infinity it slopes upwards towards the equilibrium solution at y = 1.2342

in fact since that is only a semi stable equilibrium what would probably happen in the real world is at some point the solution curves will get bumped a little bit and it would been head up and level up at y = 2.2381

So i will just say in the real world in which all solutions are constantly getting bumped or perturbed or you will always introducing small external factors into a system we would expect at some point that solution curve would get bumped a little bit about 2.2399

Above one and at that point it would immediately latch on to an upper trajectory and head up towards the stable solution at y = 2 so sort of as mathematical extraction we know that y would approach one but in practice in a long term we would expect to see y jumping pass the solution at 1 and approaching the stable solution at y = 2.2428

So just a recap there what we did was first we graphed this equation in y′ versus y so we graphed that and that is how we got this blue curve here.2458

And then by looking at that we could read off a lot information about the solutions, we could read off at our equilibrium solutions at y = 1, 2, and 3 so that is how we got these three solutions at y = 1, 2, 3 that is three horizontal lines there.2473

We could also read off information about when y′ is positive and negative from that graph and then we use those to draw those solution curves in between y′ is positive, positive, negative and positive.2489

And so once we have that we could identify which of the equilibrium where unstable, stable and semi stable.2508

Of course we could have figured that out just by looking at the original phase plane analysis because we know that stable solutions have f(y) going downwards through the axis and unstable solutions have f(y) going upwards through the axis and then this is sort of the special case.2519

So from there we got which solutions are stable, unstable and semi stable and then we look at these two initial conditions that we were given and we look at with those fell on the graph.2542

And we identified where they will go as y as t goes to infinity where the y values would go so here we saw that would the y values will go to infinity here we saw curve that would sort of in theory we go up to one but in practice it would probably get bump up to y = 2.2555

So lets try another another example here we got a failing messy differential equation here y′ is equal to y^2 - 4y^3 + 5y - 2 and so again we wanna start by drawing a graph of y′ versus y and we to identify the equilibrium solutions.2581

So this one is a little tricky because it has not been factored for us and so we have to factor a cubic here and really if you do not know how to do that a good place to look is in the educator lectures for algebra so i will cover that in detail here.2601

That i will show you that in order to factor this i wanna check for roots factors of the right hand term, the constant term here.2619

And I'm going to use synthetic substitution so on factors of 2 and since i already plan this out I'm going to try y = 2 first so I'm going to use 2 as my potential route and then I'm going to write down this coefficient 1, -4, 5, and -2.2631

So 1, -4, 5, and -2 and I'm going to do some synthetic solution here there is something you can learn about reviewing your algebra from a few years back.2652

1 i just bring that down and i get 1 multiply that by 2 and i get 2 at -4 to 2 and i get -2 multiply that by 2 and i get -4 at 5 and -4 i get 1 multiply 1 by 2 and i get 2.2664

And at -2 and 2 i get 0 what that means is that 2 is a root of that cubic and moreover it means that when i factor y - 2 from this the coefficient of the reduced equation are given exactly by 1 -2 and 1.2692

So this factors into y^2 - 2y + 1 so that is really useful because it means i can keep factoring here y - 2 and then y^2 - 2y = 1 is y - 1^2.2719

So that is just a little algebra that we have to do in order to give us some meaningful equation to solve here so now we have that we can graph this equation so I'm going to graph y′ versus y remember that is how you do that phase plane analysis y′ versus y.2739

Y′ versus y and looking at this i see that it is going to be 0 when y is 1 or 2 so there is y = 1 and there is y = 2 now this is a positive cubic curve so i know it is going to have a general shape like this.2756

And i see that y = 1 is a double root that is because of the y - 1^3 there, it is a double root which it is just going to be tangent to the axis there and then y=2 is just a single root so that is just a regular root there.2790

And now we have to identify the equilibrium solutions well that just means where y′ is equal to 0 so wherever this curve touches the horizontal axis that is where we get the equilibrium solutions so the equilibrium solutions there y = 1 and y = 2.2814

So where done with everything this example asks us because we graphed y′ as a function of y that mend factoring y in this cubic equation and of course factoring takes us all the way back to algebra so we mend to through synthetic substitution here.2836

We got 0 at the end which meant 2 is really a root of course i tried 2 first because i had already kinda plan this out i already knew 2 is already going to work .2856

if you did not know that you that you would have probably tried 1 and -1 and 2 and -2 and you are kept trying this numbers until got something that would give you a 0 at the end there.2864

But once you do get 0 then it is very nice that we get these reduced equation 1, -1, -2, 1 that tells us these coefficients here 1, -2, 1 and so that lets us factor the equation on down to y - 2 x y - 1^3.2877

And then that gives us a graph of course if you a graphing calculator and you are allowed to use it then you could have skip all that algebra and just strong as equation into your graphing calculator and of course it would give you this same kind of graph here of y′ is equal to f(y).2897

And then we identify the equilibrium solutions those are just the places where this crosses through the y axis or the horizontal axis those were the equilibrium solutions.2920

So we are going to be using this phase plane analysis in the next example to actually draw out the various kinds of solution to the differential equations.2930

So let us go ahead with that we are asked this is the same differential equation let me emphasise y^2 - 4y^3 + 5y - 2 last just sketch the other solution.2940

We are going to label the equilibrium solutions as stable, semi stable or unstable and then we are going to describe what ranges of values for an initial condition would lead to what limiting behaviour for the solution.2953

So in order to understand that let me redraw my phase plane for you remember we factor this down into y - 1^2 x y - 2 and so when we graph that we are graphing y′ versus y that is the phase plane there.2970

We had roots at y = 1 and y = 2 and then we have a curve that just goes up and just barely touch this at y = 1 and then it goes back down again and then it goes up through y = 2.2996

And we going to translate that into a graph of solutions in terms of y and t so remember when you are graphing the solutions y is the vertical axis when you are graphing the phase plane analysis y is the horizontal axis.3019

So that is always a little confusing but you wanna keep be very clear to keep track of which craft is which and do not mix them up.3037

So here I'm going to start by graphing y = 1 and y = 2 and those correspond to equilibrium solutions those are places where y′ is equal to 0.3044

So i will graph a couple of horizontal lines there those are my 2 equilibrium solutions and then i wanna figured out what the other solutions do.3060

So i will go back and look at the phase plane analysis if i look down here when y is less than 1 i see that y′ is less than 0 because the curve is down here below the axis.3073

When y is between 1 and 2 i steel see that y′ is less than 0 and then when y is bigger than 2 i see that y′ is greater than 0.3086

So I'm going to used that to draw my solution curves when y is less than 1 i have solution curves that slope downwards so i will draw these curves sloping downwards.3095

When y is between 1 and 2 i still have y′ less than 0 so I'm going to draw my curves still sloping downwards, levelling off when they get to the equilibrium solutions.3108

And when y is bigger than 2 up in this region that corresponds to this region here i see that y′ is positive so I'm going to draw my solution curves positive.3126

So on the strength of that having drawn these other solution curves i can label which of my equilibrium solutions are stable or unstable or semi stable.3143

So if i look at y′ to start with sorry or y = 1 to start with that is this the solution curve here i see that if i got bumped a little bit if you got bumped a little bit down then solution curve will go far away.3153

if you got bumped a little bit up then the solution curve would come back and approach the y = 1 again so what i have there is that y = 1 is a semi stable it depends on which direction you bumped it it is a semi stable equilibrium.3169

Y = 1 is a semi stable equilibrium because if you bump it a little bit down and then the solution curves goes far away but if you bump it far up a little bit up then the solutions come back to down to y = 1.3196

Y = 2 if I'm on that solution that equilibrium solution that equilibrium solution and i get bumped a little bit it is going to go far away and that is true it need a direction it is going to go far away so y = 2 is an unstable equilibrium because even the slightest bump will send you to a solution curve that goes far away from the equilibrium solution.3210

So even though it is an equilibrium solution it is unstable you would not expect to see it happen in real life because any slight perturbation will take the solutions far away from that.3239

So what we done is identify our two equilibrium solutions one was semi stable and one was stable we did not stable equilibria there.3255

And finally the question prompt asked us to identify which ranges of initial values will lead to which limiting behaviour for the solution so let us go back look at our solution curves.3263

We see that if we are in this region that is if y is less than if y 0 if we started the point when y 0 is less than 1 then these solution curves go down to negative infinity so y goes to as t goes to infinity as t grows the y is trending downwards to negative infinity.3283

if we start at 1 then we are just going to stay at 1 and if we start anywhere in between 1 and 2 then we are going to thrift down to 1 so i will say if y if our initial value of y is 1 or anything between 1 and 2 then y of large values will tend down towards the solution at 1.3318

if we start at 2 if y not the initial value of y is 2 then will stay exactly on that solution it will be unstable so in the real world you would not expect to see this happen but we would see for large values of time we would still see y right there there on that equilibrium solution.3349

And if we start anywhere up here if y not is anything bigger than 2 then we see that the solution curves go up to infinity so as we plug in larger and larger values for t we see that y would increase up to infinity.3378

So now if we i identify all the possible things that could happen depending on which values of y not you start at we can tell you where the ultimate behaviour will be for any given value of y not.3403

So let me just recap what we did there we started with the differential equation we had to do a lot of algebra back on the previous example to factor down into y - 1^3 x y - 2 once we had that we drew this phase plane analysis where we drew the graph of y′ versus y.3420

So we are graphing a polynomial there of course you can check that on your calculator and from there we are able to identify the equilibrium solutions at y = 1 and y = 2 and then those translated into our equilibrium solutions over here y = 1 and y = 2 that is how we got these 2 horizontal lines here.3446

Looking at it in a little more detail we see that y is negative, sorry y′ is negative when y is less than 1 y′ is negative when y is between 1 and 2 and y′ is positive when y is bigger than 2 so that helps us draw these solution curves sloping downhill when y is less than 1.3467

Still sloping downhill when y is between 1 and 2 and then sloping uphill when y is bigger than 2 so we are able to draw these solution curves and then we can look at those and identify which of our equilibria are stable or unstable.3493

Turned out that y = 1 was semi stable because solution curves sort of approaching on one side, on one side they want to tend towards that solution.3509

On the other side they run away from that solution so it is stable on one side, unstable on the other side we call it semi stable y = 2 was an unstable equilibrium because the solution curves are drifting away from it.3520

Of course we could have also notice that by looking at the original phase plane graph since at y = 2 the graph is, the curve is going upwards across the horizontal axis.3538

We know that is an unstable equilibrium and at y = 1 since it is just barely touching it is tangent to the horizontal axis we know that is a semi stable equilibrium.3552

And finally we are able to look at the solution curves and identify for any possible value of y not weather be less than 1 between 1 and 2 equal 2 or others are small mistake here i should have said y not greater than 2.3566

That corresponds to these values here when y not is greater than 2 so we are able to look at those and identify for any possible range where the solution curves will end up.3585

if you are less than 1 you are going to be going down to negative infinity, if you are between 1 and 2 you are going to be force down to this solution at y = 1.3598

if you are at 2 then you are just going to keep going exactly at y = 2 but if you are any think bigger than 2 then you are going to be going up to positive infinity.3610

So the whole point of this study of autonomous equations and phase plane analysis is that nowhere in any of this did we actually solve the differential equations.3623

instead we have these autonomous equation where we have no x's or t's on the right hand side just y's.3634

And so from that we are able produce a graph of y′ versus y and from there we are able to really get a lot informations about the actual solutions y versus t.3643

We are able to figure out the equilibrium solutions weather they are stable or unstable where the other solutions go and where you are going from the initial point.3657

So i hope you had fun practicing some of those on your own that wraps up this lecture on autonomous equations and this is part of differential equations lecture series my name is Will Murray and you are watchIng educator.com, thanks.3665
